Danfoss VLT AutomationDrive FC 301 Programming Manual page 171

Parameter Descriptions
15-10 Logging Source
Option:
[1652] Feedback[Unit]
[1657] Feedback [RPM]
[1660] Digital Input
[1662] Analog Input 53
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1689] Configurable Alarm/Warning Word
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status Word
[1860] Digital Input 2
[3110] Bypass Status Word
15-11 Logging Interval
Array [4]
Range:
Size related [ 0.000 - 0.000 ] Enter the interval in ms between
*
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specified percentage of samples before the occurrence of the
trigger event (parameter 15-14 Samples Before Trigger).
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
MG33ML02
Programming Guide
Function:
Function:
each sampling of the variables to
be logged.
Function:
Danfoss A/S © 02/2016 All rights reserved.
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specified percentage of samples before the occurrence of the
trigger event (parameter 15-14 Samples Before Trigger).
Option:
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
15-13 Logging Mode
Option: Function:
[0] Log always Select [0] Log always for continuous logging.
*
[1] Log once Select [1] Log once on trigger to conditionally
on trigger start and stop logging using
parameter 15-12 Trigger Event and
parameter 15-14 Samples Before Trigger.
15-14 Samples Before Trigger
Range: Function:
50 [0 - 100] Before a trigger event, enter the percentage of all
*
samples which should be retained in the log. See
also parameter 15-12 Trigger Event and
parameter 15-13 Logging Mode.
3.16.3 15-2* Historic Log
View up to 50 logged data items via the array parameters
in this parameter group. Data is logged every time an
event occurs (not to be confused with SLC events). Events
in this context are defined as a change in 1 of the
following areas:
•
Digital inputs.
•
Digital outputs.
•
Warning word.
•
Alarm word.
•
Status word.
3 3
