Parameter Descriptions
13-16 RS-FF Operand R
Option:
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
3 3
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq. warning
[93] ATEX ETR freq. alarm
[94] RS Flipflop 0
148
®
VLT AutomationDrive FC 301/302
Function:
[OK] is pressed. Only available on
the graphical LCP.
[Reset] is pressed. Only available
on the graphical LCP.
[◄] is pressed. Only available on
the graphical LCP.
[►] is pressed. Only available on
the graphical LCP.
▲
[ ] is pressed. Only available on
the graphical LCP.
▼
[ ] is pressed. Only available on
the graphical LCP.
Danfoss A/S © 02/2016 All rights reserved.
13-16 RS-FF Operand R
Option:
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
[102] Relay 1
[103] Relay 2
[104] Relay 3
X47/VLT
MCB 113.
[105] Relay 4
X47/VLT
MCB 113.
[106] Relay 5
X47/VLT
MCB 113.
[107] Relay 6
X47/VLT
MCB 113.
[108] Relay 7
X34/VLT
[109] Relay 8
X34/VLT
[110] Relay 9
X34/VLT
3.14.4 13-2* Timers
Use the result (true or false) from timers directly to define
an event (see parameter 13-51 SL Controller Event), or as
boolean input in a logic rule (see parameter 13-40 Logic
Rule Boolean 1, parameter 13-42 Logic Rule Boolean 2, or
parameter 13-44 Logic Rule Boolean 3). A timer is only false
when started by an action (for example [29] Start timer 1)
until the timer value entered in this parameter has elapsed.
Then it becomes true again.
All parameters in this parameter group are array
parameters with index 0–2. Select index 0 to program
timer 0, select index 1 to program timer 1, and so on.
13-20 SL Controller Timer
Range: Function:
Size [ 0 - Enter the value to define the duration of the
related 0] false output from the programmed timer. A
*
timer is only false if it is started by an
action (that is, [29] Start timer 1) and until
the given timer value has elapsed.
3.14.5 13-4* Logic Rules
Combine up to 3 boolean inputs (true/false inputs) from
timers, comparators, digital inputs, status bits, and events
using the logical operators AND, OR, and NOT. Select
boolean inputs for the calculation in parameter 13-40 Logic
Rule Boolean 1, parameter 13-42 Logic Rule Boolean 2, and
Function:
®
Extended Relay Card
®
Extended Relay Card
®
Extended Relay Card
®
Extended Relay Card
®
