13-01 Start Event
Select the boolean (true or false) input to activate smart logic
control.
Option:
[4] On reference
3 3
[5] Torque limit
[6] Current Limit
[7] Out of current
range
[8] Below I low
[9] Above I high
[10] Out of speed
range
[11] Below speed
low
[12] Above speed
high
[13] Out of feedb.
range
[14] Below feedb.
low
[15] Above feedb.
high
[16] Thermal
warning
[17] Mains out of
range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock) A (trip lock) alarm is active.
[22] Comparator 0
[23] Comparator 1
140
®
VLT AutomationDrive FC 301/302
Function:
The motor runs on reference.
The torque limit set in
parameter 4-16 Torque Limit Motor Mode
or parameter 4-17 Torque Limit Generator
Mode is exceeded.
The motor current limit set in
parameter 4-18 Current Limit is exceeded.
The motor current is outside the range
set in parameter 4-18 Current Limit.
The motor current is lower than set in
parameter 4-50 Warning Current Low.
The motor current is higher than set in
parameter 4-51 Warning Current High.
The speed is outside the range set in
parameter 4-52 Warning Speed Low and
parameter 4-53 Warning Speed High.
The output speed is lower than the
setting in parameter 4-52 Warning Speed
Low.
The output speed is higher than the
setting in parameter 4-53 Warning Speed
High.
The feedback is outside the range set in
parameter 4-56 Warning Feedback Low
and parameter 4-57 Warning Feedback
High.
The feedback is below the limit set in
parameter 4-56 Warning Feedback Low.
The feedback is above the limit set in
parameter 4-57 Warning Feedback High.
The thermal warning turns on when the
temperature exceeds the limit in the
motor, the frequency converter, the
brake resistor, or the thermistor.
The mains voltage is outside the
specified voltage range.
The output is high when the frequency
converter is running counterclockwise
(the logical product of the status bits
"running" AND "reverse").
A warning is active.
A (trip) alarm is active.
Use the result of comparator 0.
Use the result of comparator 1.
Danfoss A/S © 02/2016 All rights reserved.
13-01 Start Event
Select the boolean (true or false) input to activate smart logic
control.
Option: Function:
[24] Comparator 2 Use the result of comparator 2.
[25] Comparator 3 Use the result of comparator 3.
[26] Logic rule 0 Use the result of logic rule 0.
[27] Logic rule 1 Use the result of logic rule 1.
[28] Logic rule 2 Use the result of logic rule 2.
[29] Logic rule 3 Use the result of logic rule 3.
[33] Digital input Use the result of digital input 18.
DI18
[34] Digital input Use the result of digital input 19.
DI19
[35] Digital input Use the result of digital input 27.
DI27
[36] Digital input Use the result of digital input 29.
DI29
[37] Digital input Use the result of digital input 32.
DI32
[38] Digital input Use the result of digital input 33.
DI33
[39] Start command A start command is issued.
[40] Drive stopped A stop command (jog, stop, quick stop,
coast) is issued – and not from the SLC
itself.
[41] Reset Trip A reset is issued.
[42] Auto-reset Trip An auto reset is performed.
[43] Ok key [OK] is pressed. Only available on the
graphical LCP.
[44] Reset key [Reset] is pressed. Only available on the
graphical LCP.
[45] Left key [◄] is pressed. Only available on the
graphical LCP.
[46] Right key [►] is pressed. Only available on the
graphical LCP.
▲
[47] Up key
[ ] is pressed. Only available on the
graphical LCP.
▼
[48] Down key
[ ] is pressed. Only available on the
graphical LCP.
[50] Comparator 4 Use the result of comparator 4.
[51] Comparator 5 Use the result of comparator 5.
[60] Logic rule 4 Use the result of logic rule 4.
[61] Logic rule 5 Use the result of logic rule 5.
[76] Digital input
Use the value of x30/2 (VLT
x30/2
Purpose I/O MCB 101).
®
General
