Danfoss VLT AutomationDrive FC 301 Programming Manual page 35

Parameter Descriptions
0-20 Display Line 1.1 Small
Option: Function:
[1605] Main Actual Value Actual value as a percentage.
[%]
[1606] Actual Position
[1607] Target Position
[1608] Position Error
[1609] Custom Readout
[1610] Power [kW] Actual power consumed by the
motor in kW.
[1611] Power [hp] Actual power consumed by the
motor in hp.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Frequency Motor frequency, that is the output
frequency from the frequency
converter in Hz.
[1614] Motor current Phase current of the motor
measured as effective value.
[1615] Frequency [%] Motor frequency, that is the output
frequency from the frequency
converter in percent.
[1616] Torque [Nm] Actual motor torque in Nm.
[1617] Speed [RPM] Speed in RPM (revolutions per
minute), that is the motor shaft
*
speed in closed loop.
[1618] Motor Thermal Thermal load on the motor,
calculated by the ETR function.
[1619] KTY sensor
temperature
[1620] Motor Angle
[1621] Torque [%] High
Res.
[1622] Torque [%] Present motor load as a percentage
of the rated motor torque.
[1623] Motor Shaft Power
[kW]
[1624] Calibrated Stator
Resistance
[1625] Torque [Nm] High
[1630] DC Link Voltage DC-link voltage in the frequency
converter.
[1632] Brake Energy /s Present brake power transferred to
an external brake resistor.
Stated as an instant value.
[1633] Brake Energy Brake power transferred to an
Average external brake resistor. The mean
power is calculated continuously
for the most recent 120 s.
[1634] Heatsink Temp. Present heat sink temperature of
the frequency converter. The cut-
MG33ML02
Programming Guide
0-20 Display Line 1.1 Small
Option:
[1635]
[1636]
[1637]
[1638]
[1639]
[1644]
[1645]
[1646]
[1647]
[1648]
[1650]
[1651]
[1652]
[1653]
[1657]
[1660]
[1661]
[1662]
[1663]
[1664]
[1665]
[1666]
Danfoss A/S © 02/2016 All rights reserved.
Function:
out limit is 95 ±5 °C; cutting back
in occurs at 70 ±5 °C.
Inverter Thermal Percentage load of the inverters.
Inv. Nom. Current Nominal current of the frequency
converter.
Inv. Max. Current Maximum current of the frequency
converter.
SL Controller State State of the event executed by the
control.
Control Card Temp. Temperature of the control card.
Speed Error [RPM]
Motor Phase U
Current
Motor Phase V
Current
Motor Phase W
Current
Speed Ref. After
Ramp [RPM]
External Reference Sum of the external reference as a
percentage, that is the sum of
analog/pulse/bus.
Pulse Reference Frequency in Hz connected to the
digital inputs (18, 19 or 32, 33).
Feedback[Unit] Reference value from programmed
digital inputs.
Digi Pot Reference
Feedback [RPM]
Digital Input Signal states from the 6 digital
terminals (18, 19, 27, 29, 32, and
33). There are 16 bits in total, but
only 6 of them are used. Input 18
corresponds to the far left of the
used bits. Signal low = 0; Signal
high = 1.
Terminal 53 Switch Setting of input terminal 54.
Setting Current = 0; Voltage = 1.
Analog Input 53 Actual value at input 53 either as a
reference or protection value.
Terminal 54 Switch Setting of input terminal 54.
Setting Current = 0; Voltage = 1.
Analog Input 54 Actual value at input 54 either as
reference or protection value.
Analog Output 42 Actual value at output 42 in mA.
[mA] Use parameter 6-50 Terminal 42
Output to select the value to be
shown.
Digital Output [bin] Binary value of all digital outputs.
