Parameter Descriptions
13-40 Logic Rule Boolean 1
Option:
[85] Digital input x46/13
[90] ATEX ETR cur. warning
3 3
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq.
warning
[93] ATEX ETR freq. alarm
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
[102] Relay 1
[103] Relay 2
[104] Relay 3
[105] Relay 4
[106] Relay 5
[107] Relay 6
150
®
VLT AutomationDrive FC 301/302
Function:
Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 164, ATEX ETR cur.lim.alarm
is active, the output is 1.
Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 166, ATEX ETR freq.lim.alarm
is active, the output is 1.
Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 163, ATEX ETR cur.lim.warning
is active, the output is 1.
Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
warning 165, ATEX ETR
freq.lim.warning is active, the
output is 1.
See chapter 3.14.2 13-1*
Comparators.
See chapter 3.14.2 13-1*
Comparators.
See chapter 3.14.2 13-1*
Comparators.
See chapter 3.14.2 13-1*
Comparators.
See chapter 3.14.2 13-1*
Comparators.
See chapter 3.14.2 13-1*
Comparators.
See chapter 3.14.2 13-1*
Comparators.
See chapter 3.14.2 13-1*
Comparators.
®
X47/VLT Extended Relay Card
MCB 113.
®
X47/VLT Extended Relay Card
MCB 113.
®
X47/VLT Extended Relay Card
MCB 113.
®
X47/VLT Extended Relay Card
MCB 113.
Danfoss A/S © 02/2016 All rights reserved.
13-40 Logic Rule Boolean 1
Option: Function:
[108] Relay 7
X34/VLT
[109] Relay 8
X34/VLT
[110] Relay 9
X34/VLT
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
st
Select the 1 logical operator to use on the
boolean inputs from parameter 13-40 Logic Rule
Boolean 1 and parameter 13-42 Logic Rule
Boolean 2.
Parameter numbers in square brackets stand
for the boolean inputs of parameters in
chapter 3.14 Parameters: 13-** Smart Logic
Control.
[0] DISABLED Ignores:
•
Parameter 13-42 Logic Rule Boolean 2.
•
Parameter 13-43 Logic Rule Operator 2.
•
Parameter 13-44 Logic Rule Boolean 3.
[1] AND Evaluates the expression [13-40] AND [13-42].
[2] OR Evaluates the expression [13-40] OR [13-42].
[3] AND NOT Evaluates the expression [13-40] AND NOT
[13-42].
[4] OR NOT Evaluates the expression [13-40] OR NOT
[13-42].
[5] NOT AND Evaluates the expression NOT [13-40] AND
[13-42].
[6] NOT OR Evaluates the expression NOT [13-40] OR
[13-42].
[7] NOT AND Evaluates the expression NOT [13-40] AND NOT
NOT [13-42].
[8] NOT OR Evaluates the expression NOT [13-40] OR NOT
NOT [13-42].
13-42 Logic Rule Boolean 2
Option: Function:
[0] False
Select the 2
false) input for the selected logic
rule. See parameter 13-01 Start
Event and parameter 13-02 Stop
Event for more information.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
®
Relay Card MCB 105.
®
Relay Card MCB 105.
®
Relay Card MCB 105.
nd boolean (true or
