Parameter Descriptions
13-52 SL Controller Action
Option:
[20] Select ramp 3
[21] Select ramp 4
3 3
[22] Run
[23] Run reverse
[24] Stop
[25] Qstop
[26] Dcstop
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out
A low
[33] Set digital out
B low
[34] Set digital out
C low
[35] Set digital out
D low
[36] Set digital out
E low
[37] Set digital out
F low
[38] Set digital out
A high
[39] Set digital out
B high
[40] Set digital out
C high
[41] Set digital out
D high
[42] Set digital out
E high
156
®
VLT AutomationDrive FC 301/302
Function:
Selects ramp 3.
Selects ramp 4.
Issues a start command to the frequency
converter.
Issues a start reverse command to the
frequency converter.
Issues a stop command to the frequency
converter.
Issues a quick stop command to the
frequency converter.
Issues a DC stop command to the
frequency converter.
The frequency converter coasts
immediately. All stop commands including
the coast command stop the SLC.
Freezes the output frequency of the
frequency converter.
Starts timer 0, see parameter 13-20 SL
Controller Timer for further description.
Starts timer 1, see parameter 13-20 SL
Controller Timer for further description.
Starts timer 2, see parameter 13-20 SL
Controller Timer for further description.
Any output with smart logic output A is
low.
Any output with smart logic output B is
low.
Any output with smart logic output C is
low.
Any output with smart logic output D is
low.
Any output with smart logic output E is
low.
Any output with smart logic output F is
low.
Any output with smart logic output A is
high.
Any output with smart logic output B is
high.
Any output with smart logic output C is
high.
Any output with smart logic output D is
high.
Any output with smart logic output E is
high.
Danfoss A/S © 02/2016 All rights reserved.
13-52 SL Controller Action
Option: Function:
[43] Set digital out Any output with smart logic output F is
F high high.
[60] Reset Counter Resets counter A to 0.
A
[61] Reset Counter Resets counter B to 0.
B
[70] Start timer 3 Start timer 3, see parameter 13-20 SL
Controller Timer for further description.
[71] Start timer 4 Start timer 4, see parameter 13-20 SL
Controller Timer for further description.
[72] Start timer 5 Start timer 5, see parameter 13-20 SL
Controller Timer for further description.
[73] Start timer 6 Start timer 6, see parameter 13-20 SL
Controller Timer for further description.
[74] Start timer 7 Start timer 7, see parameter 13-20 SL
Controller Timer for further description.
