Parameter Descriptions

3.22 Parameters: 32-** MCO Basic Settings

Parameters in this group are available when VLT
Control Option MCO 305 is installed in the frequency
converter. For information about the option, see the VLT
Motion Control Option MCO 305 Operating Instructions.
3.23 Parameters: 33-** MCO Advanced
Settings
Parameters in this group are available when VLT
Control Option MCO 305 is installed in the frequency
converter. For information about the option, see the VLT
Motion Control Option MCO 305 Operating Instructions.

3.24 Parameters: 34-** MCO Data Readouts

Parameters in this group are available when VLT
Control Option MCO 305 is installed in the frequency
converter. For information about the option, see the VLT
Motion Control Option MCO 305 Operating Instructions.

3.25 Parameters: 35-** Sensor Input Option

Parameters for configuring the functionality of VLT
Input MCB 114.
3.25.1 35-0* Temp. Input Mode (MCB 114)
35-00 Term. X48/4 Temperature Unit
Select the unit to be used with temperature input X48/4 settings
and readouts:
Option:
[60] °C
*
[160] °F
35-01 Term. X48/4 Input Type
View the temperature sensor type detected at input X48/4:
Option:
[0] Not Connected
*
[1] PT100 2-wire
[3] PT1000 2-wire
[5] PT100 3-wire
[7] PT1000 3-wire
35-02 Term. X48/7 Temperature Unit
Select the unit to be used with temperature input X48/7 settings
and readouts:
Option:
[60] °C
*
[160] °F
35-03 Term. X48/7 Input Type
View the temperature sensor type detected at input X48/7:
Option:
[0] Not Connected
*
[1] PT100 2-wire
MG33ML02
Programming Guide
35-03 Term. X48/7 Input Type
View the temperature sensor type detected at input X48/7:
®
Motion
Option:
[3]
®
[5]
[7]
35-04 Term. X48/10 Temperature Unit
Select the unit to be used with temperature input X48/10
®
Motion
settings and readouts:
Option:
®
[60]
[160]
35-05 Term. X48/10 Input Type
®
Motion
View the temperature sensor type detected at input X48/10:
Option:
®
[0]
[1]
[3]
[5]
®
Sensor
[7]
35-06 Temperature Sensor Alarm Function
Select the alarm function:
Option:
[0]
[2]
[5]
[27]
Function:
3.25.2 35-1* Temp. Input X48/4 (MCB 114)
35-14 Term. X48/4 Filter Time Constant
Range:
Function:
0.001 s
35-15 Term. X48/4 Temp. Monitor
This parameter facilitates the possibility of enabling or disabling
Function: the temperature monitor for terminal X48/4. Set the temperature
limits in parameter 35-16 Term. X48/4 Low Temp. Limit and
parameter 35-17 Term. X48/4 High Temp. Limit.
Option:
[0]
[1]
Function:
Danfoss A/S © 02/2016 All rights reserved.
PT1000 2-wire
PT100 3-wire
PT1000 3-wire
°C
*
°F
Not Connected
*
PT100 2-wire
PT1000 2-wire
PT100 3-wire
PT1000 3-wire
Off
Stop
Stop and trip
*
Forced stop and trip
Function:
[0.001 - 10 Enter the filter time constant. This is a
*
s] first-order digital low-pass filter time
constant for suppressing electrical noise
in terminal X48/4. A high time constant
value improves dampening but also
increases the time delay through the
filter.
Disabled
*
Enabled
Function:
3
Function:
Function:
Function:
Function:
189
3
