Danfoss VLT AutomationDrive FC 301 Programming Manual page 137

Parameter Descriptions
8-41 Parameters for Signals
Option:
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1678] Analog Out X45/1 [mA]
[1679] Analog Out X45/3 [mA]
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1683] Fieldbus REF 2
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1687] Bus Readout Alarm/Warning
[1689] Configurable Alarm/Warning Word
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1836] Analog Input X48/2 [mA]
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
[1839] Temp. Input X48/10
[1860] Digital Input 2
[4280] Safe Option Status
[4282] Safe Control Word
[4283] Safe Status Word
[4285] Active Safe Func.
8-42 PCD Write Configuration
Range: Function:
Size [0 - Select the parameters to be assigned to
related 9999] the PCD's telegrams. The number of
*
available PCDs depends on the telegram
type. The values in the PCDs are then
written to the selected parameters as
data values.
8-43 PCD Read Configuration
Range: Function:
Size [0 - Select the parameters to be assigned to
related 9999] the PCDs of the telegrams. The number
*
of available PCDs depends on the
telegram type. PCDs contain the actual
data values of the selected parameters.
8-45 BTM Transaction Command
Option: Function:
NOTICE
This parameter cannot be
adjusted while the motor runs.
[0] Off
*
MG33ML02
Programming Guide
8-45 BTM Transaction Command
Function: Option:
[1]
[2]
[3]
8-46 BTM Transaction Status
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
8-47 BTM Timeout
Range:
60 s
*
8-48 BTM Maximum Errors
Range:
21
*
8-49 BTM Error Log
Range:
0.255
3.10.5 8-5* Digital/Bus
Parameters for configuring the control word merging.
NOTICE
These parameters are active only when
parameter 8-01 Control Site is set to [0] Digital and control
word.
8-50 Coasting Select
Option:
[0]
[1]
[2]
Danfoss A/S © 02/2016 All rights reserved.
Function:
Start Transaction
Commit transaction
Clear error
Off
Transaction Started
Transaction Comitting
Transaction Timeout
Err. Non-existing Par.
Err. Par. Out of Range
Transaction Failed
Function:
[1 - 360 s] Select the BTM timeout after a BTM
transaction has been started.
Function:
[0 - 21] Selects the maximum allowed number of bulk
transfer mode errors before aborting. If it is set to
maximum, there is no abort.
Function:
[0.000 - List of parameters that failed during
*
9999.255] bulk transfer mode. The value after the
decimal break is the fault code (255
stands for no error).
Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
Digital Activates start command via a digital input.
input
Bus Activates start command via the serial
communication port or fieldbus option.
Logic AND Activates start command via the fieldbus/serial
communication port and 1 extra digital input.
3 3
Function:
135
