Danfoss VLT AutomationDrive FC 301 Programming Manual page 135

Parameter Descriptions
8-17 Configurable Alarm and Warningword
The configurable alarm and warning word has 16 bits (0-15).
Each of those bits can be configured to any of the following
options.
Option:
[10166] ATEX ETR freq limit alarm
8-19 Product Code
Range:
Size [0 -
related 2147483647]
*
3.10.3 8-3* FC Port Settings
8-30 Protocol
Option: Function:
Select the protocol to be used. Changing
protocol is not effective until after powering
off the frequency converter.
[0] FC
*
[1] FC MC
[2] Modbus RTU
8-31 Address
Range: Function:
Size related [ 1 - 255 ] Enter the address for the frequency
*
converter (standard) port.
Valid range: 1–126.
8-32 FC Port Baud Rate
Option: Function:
[0] 2400 Baud Baud rate selection for the FC (standard) port.
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
8-33 Parity / Stop Bits
Option:
[0] Even Parity, 1 Stop Bit
*
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-34 Estimated cycle time
Range: Function:
0 ms [0 - In noisy environments, the interface may
*
1000000 ms] be blocked due to overload or bad frames.
MG33ML02
Programming Guide
Function:
Function:
Select 0 to read out the actual
fieldbus product code according
to the mounted fieldbus option.
Select 1 to read out the actual
vendor ID.
Function:
Danfoss A/S © 02/2016 All rights reserved.
8-34 Estimated cycle time
Range: Function:
This parameter specifies the time between
2 consecutive frames on the network. If the
interface does not detect valid frames in
that time, it flushes the receive buffer.
8-35 Minimum Response Delay
Range: Function:
10 ms [ 1 - 10000 Specify the minimum delay time
*
ms] between receiving a request and
transmitting a response. This is used for
overcoming modem turnaround delays.
8-36 Max Response Delay
Range: Function:
Size [ 11 - Specify the maximum permissible
related 10001 ms] delay time between transmitting a
*
request and receiving a response. If a
response from the frequency converter
is exceeding the time setting, then it is
discarded.
8-37 Max Inter-Char Delay
Range: Function:
Size [ 0.00 - Specify the maximum permissible time
related 35.00 ms] interval between receipt of 2 bytes. This
*
parameter activates timeout if
transmission is interrupted.
This parameter is active only when
parameter 8-30 Protocol is set to [1] FC MC
protocol.
3.10.4 8-4* FC MC Protocol Set
8-40 Telegram Selection
Option: Function:
[1] Standard telegram 1 Enables use of freely configurable
*
telegrams or standard telegrams for
the FC port.
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1 Enables use of freely configurable
telegrams or standard telegrams for
the FC port.
[202] Custom telegram 3
3 3
133
