How to Program

2.1.14 Value, Step-by-Step

2 2
Certain parameters can be changed step by step. This
applies to 1-20 Motor Power [kW], 1-22 Motor Voltage and
1-23 Motor Frequency.
The parameters are changed both as a group of numeric
data values and as numeric data values that are infinitely
varying.
2.1.15 Readout and Programming of
Indexed Parameters
Parameters are indexed when placed in a rolling stack.
Parameter 15-30 Fault Log: Error Code to
parameter 15-32 Alarm Log: Time contain a fault log, which
can be read out. Select a parameter, press [OK], and press
▲ ▼
the keys [ ] [
For example, this is how parameter 3-10 Preset Reference is
changed:
Select the parameter, press [OK], and press [
through the indexed values. To change the parameter
value, select the indexed value and press [OK]. Change the
value by pressing [
setting. Press [Cancel] to abort. Press [Back] to leave the
parameter.
The following instructions are valid for the Numerical LCP
(LCP 101).
The control panel is divided into 4 functional groups:
1. Numerical display.
2. Menu keys and indicator lights - changing
parameters and switching between display
functions.
3. Navigation keys and indicator lights (LEDs).
4. Operation keys and indicator lights (LEDs).
Display line: Status messages displaying icons and
numeric value
Indicator lights (LEDs)
•
Green LED/On: Indicates if control section is on.
•
Yellow LED/Wrn.: Indicates a warning.
•
Flashing red LED/Alarm: Indicates an alarm.
LCP keys
[Menu]
Select one of the following modes:
•
Status
•
Quick Set-up
•
Main Menu
20
VLT
] to scroll through the value log.
▲ ▼
] [ ]. Press [OK] to accept the new
Danfoss A/S © Rev. 10/2014 All rights reserved.
®
AutomationDrive FC 301/302
1
2
▲ ▼
] [ ] to scroll
On
3
Warn.
Alarm
4
Illustration 2.21 LCP Keys
Status mode
Status mode displays the status of the frequency converter
or the motor.
If an alarm occurs, the NLCP automatically switches to
Status mode.
A number of alarms can be displayed.
NOTICE
Parameter copy is not possible with LCP 101 numerical
local control panel.
Illustration 2.22 Status Mode
Status Quick
Setup
Menu
OK
Hand Auto
O
on on
22.8
Setup
Main
Menu
Reset
rpm
Setup 1
