Danfoss VLT AutomationDrive FC 301 Programming Manual page 114

Parameter Descriptions
6-12 Terminal 53 Low Current
Range:
3 3
6-13 Terminal 53 High Current
Range:
20 mA [ par. 6-12 -
*
20 mA]
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0 [-999999.999 -
*
999999.999 ]
6-15 Terminal 53 High Ref./Feedb. Value
Range:
Size [-999999.999 -
related 999999.999
*
ReferenceFeed-
backUnit]
6-16 Terminal 53 Filter Time Constant
Range:
0.001 s [0.001 - 10
*
s]
112
VLT
Function:
the live zero timeout function in
parameter 6-01 Live Zero Timeout Function.
Function:
Enter the high current value
corresponding to the high reference/
feedback set in parameter 6-15 Terminal 53
High Ref./Feedb. Value.
Function:
Enter the analog input scaling value that
corresponds to the low voltage/low
current set in parameter 6-10 Terminal 53
Low Voltage and parameter 6-12 Terminal
53 Low Current.
Function:
Enter the analog input scaling
value that corresponds to the
maximum reference feedback
value set in
parameter 6-11 Terminal 53 High
Voltage and
parameter 6-13 Terminal 53 High
Current.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Enter the filter time constant. This
constant is a first-order digital low-pass
filter time for suppressing electrical noise
in terminal 53. A high value improves
dampening, but also increases the delay
through the filter.
Danfoss A/S © 02/2016 All rights reserved.
®
AutomationDrive FC 301/302
3.8.3 6-2* Analog Input 2
Parameters for configuring the scaling and limits for analog
input 2 (terminal 54).
6-20 Terminal 54 Low Voltage
Range:
0.07 V [ -10.00 -
*
par. 6-21 V]
6-21 Terminal 54 High Voltage
Range:
10 V [ par. 6-20
*
- 10 V]
6-22 Terminal 54 Low Current
Range:
0.14 [ 0 -
mA par. 6-23
*
mA]
6-23 Terminal 54 High Current
Range:
20 mA [ par. 6-22
*
- 20 mA]
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0 ReferenceFeed-
backUnit
*
Function:
Enter the low voltage value. This analog
input scaling value should correspond to
the minimum reference value, set in
parameter 3-02 Minimum/Offset Reference.
See also chapter 3.5 Parameters: 3-**
Reference/Ramps.
Function:
Enter the high-voltage value. This analog
input scaling value should correspond to the
high reference feedback value set in
parameter 6-25 Terminal 54 High Ref./Feedb.
Value.
Function:
Enter the low current value. This reference
signal should correspond to the minimum
reference value, set in
parameter 3-02 Minimum/Offset Reference.
Enter the value that exceeds 2 mA to activate
the live zero timeout function in
parameter 6-01 Live Zero Timeout Function.
Function:
Enter the high current value
corresponding to the high reference
feedback value set in
parameter 6-25 Terminal 54 High Ref./Feedb.
Value.
Function:
[-999999.999 - Enter the analog input
999999.999 scaling value that
ReferenceFeed- corresponds to the
backUnit] minimum reference
feedback value set in
parameter 3-02 Minimum/
Offset Reference.
MG33ML02
