How to Programme
2.1.10 Changing Data
The procedure for changing data is the same in the Quick
menu and the Main menu mode. Press [OK] to change the
selected parameter.
The procedure for changing data depends on whether the
selected parameter represents a numerical data value or a
text value.
2.1.11 Changing a Text Value
If the selected parameter is a text value, change the text
▲
▼
value with the [
] [
] keys.
Place the cursor on the value to save and press [OK].
740RPM
Basic Settings
0 -01 Language
[0] English
Illustration 2.16 Changing a Text Value
2.1.12 Changing
If the chosen parameter represents a numeric data value,
change the chosen data value by means of the [
navigation keys as well as the [
◀
▶
[
] [
] keys to move the cursor horizontally.
113 RPM
Load depen. setting
1 - 60 Low speed load
compensation
100%
Illustration 2.17 Changing a Data Value
▲
▼
Press [
] [
] keys to change the data value. [
▼
the data value, and [
] decreases the data value. Place the
cursor on the value to save and press [OK].
®
VLT
AutomationDrive Programming Guide
10.64 A
1 [1]
0-0 *
◀
▶
] [
]
▲
▼
] [
] navigation keys. Press
1.78 A
1(1)
1- 6*
▲
] increases
®
MG33MG02 - VLT
is a registered Danfoss trademark
729RPM
Load depen. setting
1 - 60 Low speed load
compensation
1 0%
6
Illustration 2.18 Saving a Data Value
2.1.13 Infinitely Variable Change of
Numeric Data Value
If the chosen parameter represents a numeric data value,
◀
▶
select a digit with [
] [
].
635 RPM
Start Adjustments
1 - 71 Start Delay
00.0s
Illustration 2.19 Selecting a Digit
Change the selected digit infinitely variably with [
The chosen digit is indicated by the cursor. Place the
cursor on the digit to save and press [OK].
957RPM
Start Adjustments
1-71 High starting torque time
0. s
4
Illustration 2.20 Saving
2.1.14 Value, Step-by-Step
Certain parameters can be changed step by step or
infinitely varying. This applies to 1-20 Motor Power [kW],
1-22 Motor Voltage and 1-23 Motor Frequency.
The parameters are changed both as a group of numeric
data values and as numeric data values infinitely varying.
6.21A
1(1)
1- 6*
0.44 A
1 (1)
1- 7*
▲
▼
] [
].
11.58A
1 (1)
1-7*
19
2
2
