Parameter Descriptions
3-10 Preset Reference
Array [8]
Range: 0-7
Range: Function:
corresponding digital inputs in parameter group
5-1* Digital Inputs.
12 (+24V)
Preset 76543210
10101010 29 [P 5-13=Preset ref. bit 0]
32 [P 5-14=Preset ref. bit 1]
11001100
11110000 33 [P 5-15=Preset ref. bit 2]
Illustration 3.21 Preset Reference
Preset ref. bit
Preset ref. 0
Preset ref. 1
Preset ref. 2
Preset ref. 3
Preset ref. 4
Preset ref. 5
Preset ref. 6
Preset ref. 7
Table 3.13 Preset Reference Bits
3-11 Jog Speed [Hz]
Range: Function:
Size [ 0 - par. The jog speed is a fixed output speed at
related 4-14 Hz] which the frequency converter is
*
running, when the jog function is
activated.
See also parameter 3-80 Jog/Homing
Ramp Time.
3-12 Catch up/slow Down Value
Range: Function:
0 % [0 - Enter a percentage (relative) value to be either
*
100 %] added to or deducted from the actual reference
for catch up or slow down. If catch up is selected
via 1 of the digital inputs (parameter 5-10 Terminal
18 Digital Input to parameter 5-15 Terminal 33
Digital Input), the percentage (relative) value is
added to the total reference. If slow down is
selected via 1 of the digital inputs
(parameter 5-10 Terminal 18 Digital Input to
parameter 5-15 Terminal 33 Digital Input), the
percentage (relative) value is deducted from the
total reference. Obtain extended functionality with
MG33ML02
Programming Guide
2 1 0
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
