Parameter Descriptions
13-51 SL Controller Event
Option:
[1] True
[2] Running
[3] In range
3 3
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
154
®
VLT AutomationDrive FC 301/302
Function:
[OK] is pressed. Only available on
the graphical LCP.
[Reset] is pressed. Only available
on the graphical LCP.
[◄] is pressed. Only available on
the graphical LCP.
[►] is pressed. Only available on
the graphical LCP.
Danfoss A/S © 02/2016 All rights reserved.
13-51 SL Controller Event
Option: Function:
▲
[47] Up key
[
the graphical LCP.
▼
[48] Down key
[
the graphical LCP.
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 164, ATEX ETR cur.lim.alarm is
active, the output is 1.
[91] ATEX ETR cur. alarm Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR]. If
alarm 166, ATEX ETR freq.lim.alarm
is active, the output is 1.
[92] ATEX ETR freq. Available, if parameter 1-90 Motor
warning Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 163, ATEX ETR cur.lim.warning
is active, the output is 1.
[93] ATEX ETR freq. alarm Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
warning 165, ATEX ETR
freq.lim.warning is active, the
output is 1.
[94] RS Flipflop 0 See chapter 3.14.2 13-1*
Comparators.
[95] RS Flipflop 1 See chapter 3.14.2 13-1*
Comparators.
] is pressed. Only available on
] is pressed. Only available on
