Parameter Descriptions
13-10 Comparator Operand
Option: Function:
[151] SL digital Use the result of the SLC output B.
output B
[152] SL digital Use the result of the SLC output C.
output C
[153] SL digital Use the result of the SLC output D.
output D
[154] SL digital Use the result of the SLC output E.
output E
[155] SL digital Use the result of the SLC output F.
output F
[160] Relay 1 Relay 1 is active.
[161] Relay 2 Relay 2 is active.
[162] Relay 3
[163] Relay 4
[164] Relay 5
[165] Relay 6
[166] Relay 7
[167] Relay 8
[168] Relay 9
[180] Local referecnce Active when parameter 3-13 Reference Site
active is [2] Local or when
parameter 3-13 Reference Site is [0] Linked
to hand Auto, at the same time as the
LCP is in hand on mode.
[181] Remote Active when parameter 3-13 Reference Site
reference active is [1] Remote or [0] Linked to hand/auto,
while the LCP is in auto on mode.
[182] Start command Active when there is an active start
command, and no stop command.
[183] Drive stopped A stop command (jog, stop, qstop, coast)
is issued – and not from the SLC itself.
[185] Drive in hand Active when the frequency converter is in
mode hand on mode.
[186] Drive in auto Active when the frequency converter is in
mode auto mode.
[187] Start command
given
[190] Digital input
x30/2
[191] Digital input
x30/3
[192] Digital input
x30/4
[193] Digital input
x46/1
[194] Digital input
x46/3
[195] Digital input
x46/5
[196] Digital input
x46/7
MG33ML02
Programming Guide
13-10 Comparator Operand
Option:
[197] Digital input
x46/9
[198] Digital input
x46/11
[199] Digital input
x46/13
13-11 Comparator Operator
Option:
[0] <
[1] ≈ (equal)
[2] >
[5] TRUE
longer
than..
[6] FALSE
longer
than..
[7] TRUE
shorter
than..
[8] FALSE
shorter
than..
13-12 Comparator Value
Array [6]
Range:
Size
related
*
