Danfoss VLT AutomationDrive FC 301 Programming Manual page 157

Parameter Descriptions
13-51 SL Controller Event
Option:
[96] RS Flipflop 2 See chapter 3.14.2 13-1*
Comparators.
[97] RS Flipflop 3 See chapter 3.14.2 13-1*
Comparators.
[98] RS Flipflop 4 See chapter 3.14.2 13-1*
Comparators.
[99] RS Flipflop 5 See chapter 3.14.2 13-1*
Comparators.
[100] RS Flipflop 6 See chapter 3.14.2 13-1*
Comparators.
[101] RS Flipflop 7 See chapter 3.14.2 13-1*
Comparators.
[102] Relay 1
[103] Relay 2
[104] Relay 3
X47/VLT
MCB 113.
[105] Relay 4
X47/VLT
MCB 113.
[106] Relay 5
X47/VLT
MCB 113.
[107] Relay 6
X47/VLT
MCB 113.
[108] Relay 7
X34/VLT
[109] Relay 8
X34/VLT
[110] Relay 9
X34/VLT
13-52 SL Controller Action
Option: Function:
Select the action corresponding to the SLC
event. Actions are executed when the
corresponding event (defined in
parameter 13-51 SL Controller Event) is
evaluated as true.
[0] DISABLED
[1] No action
[2] Select set-up 1 Changes the active set-up
(parameter 0-10 Active Set-up) to 1.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
[3] Select set-up 2 Changes the active set-up
parameter 0-10 Active Set-up) to 2.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
[4] Select set-up 3 Changes the active set-up
(parameter 0-10 Active Set-up) to 3.
MG33ML02
Programming Guide
Function:
®
Extended Relay Card
®
Extended Relay Card
®
Extended Relay Card
®
Extended Relay Card
®
Relay Card MCB 105.
®
Relay Card MCB 105.
®
Relay Card MCB 105.
Danfoss A/S © 02/2016 All rights reserved.
13-52 SL Controller Action
Option: Function:
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
[5] Select set-up 4 Changes the active set-up
(parameter 0-10 Active Set-up) to 4.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
[10] Select preset Selects preset reference 0.
ref 0 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[11] Select preset Selects preset reference 1.
ref 1 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[12] Select preset Selects preset reference 2.
ref 2 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[13] Select preset Selects preset reference 3.
ref 3 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[14] Select preset Selects preset reference 4.
ref 4 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[15] Select preset Selects preset reference 5.
ref 5 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[16] Select preset Selects preset reference 6.
ref 6 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[17] Select preset Selects preset reference 7.
ref 7 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
3 3
155
