Danfoss VLT AutomationDrive FC 301 Programming Manual page 77

Parameter Descriptions
3-18 Relative Scaling Reference Resource
Option: Function:
variable values (labeled Y in
Illustration 3.24) is multiply by the
actual reference (labeled X in
Illustration 3.24). This product is then
added to the actual reference (X+X*Y/
100) to give the resulting actual
reference.
Y
X
Illustration 3.24 Resulting Actual
Reference
[0] No function
*
[1] Analog Input 53
[2] Analog Input 54
[3] 24V encoder
[4] MCB 102
[5] MCB 103
[7] Frequency input
29
[8] Frequency input
33
[11] Local bus reference
[20] Digital pot.meter
[21] Analog input
X30/11
[22] Analog input
X30/12
[29] Analog Input
X48/2
3-19 Jog Speed [RPM]
Range: Function:
Size [ 0 - Enter a value for the jog speed n
related par. 4-13 is a fixed output speed. The frequency
*
RPM] converter runs at this speed when the jog
function is activated. The maximum limit is
defined in parameter 4-13 Motor Speed High
Limit [RPM].
See also parameter 3-80 Jog/Homing Ramp
Time.
MG33ML02
Programming Guide
Resulting
Relative Z
actual
Z=X+X*Y/100
reference
, which
JOG
Danfoss A/S © 02/2016 All rights reserved.
3.5.3 3-2* References II
3-20 Preset Target
Array [8]
Set up to 8 target positions. Select from the 8 preset positions
using digital inputs or the fieldbus control word.
Range:
0 CustomRea- [ -2000000000 -
doutUnit2 2000000000
*
CustomReadoutUnit2]
3-21 Touch Target
Enter the target position in touch probe positioning mode. This
parameter defines the distance from the detection event of the
touch probe sensor to the final target position in position units.
Range:
0 CustomRea- [ -2000000000 -
doutUnit2 2000000000
*
CustomReadoutUnit2]
3-22 Master Scale Numerator
Parameter 3-22 Master Scale Numerator and parameter 3-23 Master
Scale Denominator define the gear ratio between the master and
the follower in synchronization mode.
Par . 3 − 22
Master revolutions =
Par . 3 − 23
Range:
1 [-2000000000 -
*
2000000000]
3-23 Master Scale Denominator
See parameter 3-22 Master Scale Numerator.
Range:
1 [-2000000000 - 2000000000]
*
3-24 Master Lowpass Filter Time
Enter the time constant for master speed calculation in synchro-
nizing mode.
Range:
20 ms [1 - 2000 ms]
*
3-25 Master Bus Resolution
Enter the resolution of the fieldbus master signal (fieldbus
reference 1) in synchronization mode.
Range:
65536 [128 - 65536]
*
Function:
Function:
× Follower revolutions
Function:
Function:
Function:
Function:
75
3 3
