Parameter Descriptions
0-30 Unit for User-defined Readout
Option:
[25] m³/h
[30] kg/s
[31] kg/min
3 3
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
0-31 Min Value of User-defined Readout
Range:
0 CustomRea-
doutUnit
*
36
VLT
Function:
Function:
[ -999999.99 - This parameter sets the min.
par. 0-32 value of the custom-defined
CustomRea- readout (occurs at zero speed).
doutUnit] Only possible to set different
from 0 when selecting a linear
unit in parameter 0-30 Unit for
User-defined Readout. For
quadratic and cubic units, the
minimum value is 0.
Danfoss A/S © 02/2016 All rights reserved.
®
AutomationDrive FC 301/302
0-32 Custom Readout Max Value
Range:
100 Custom-
ReadoutUnit
0-37 Display Text 1
Range:
0 [0 -
*
25]
0-38 Display Text 2
Range:
0 [0 -
*
25]
0-39 Display Text 3
Range:
0 [0 -
*
25]
3.2.5 0-4* LCP Keypad
Enable, disable, and password protect individual keys on
the LCP.
Function:
[ par. 0-31 - This parameter sets the
999999.99 maximum value to be shown
*
CustomRea- when the speed of the motor
doutUnit] has reached the set value for
parameter 4-13 Motor Speed High
Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed
Unit).
Function:
Enter a text which can be viewed in the graphical
display by selecting [37] Display Text 1 in
•
Parameter 0-20 Display Line 1.1 Small,
•
Parameter 0-21 Display Line 1.2 Small,
•
Parameter 0-22 Display Line 1.3 Small,
•
Parameter 0-23 Display Line 2 Large, or
•
Parameter 0-24 Display Line 3 Large.
Function:
Enter a text which can be viewed in the graphical
display by selecting [38] Display Text 2 in
•
parameter 0-20 Display Line 1.1 Small,
•
parameter 0-21 Display Line 1.2 Small,
•
parameter 0-22 Display Line 1.3 Small,
•
parameter 0-23 Display Line 2 Large, or
•
parameter 0-24 Display Line 3 Large.
Function:
Enter a text which can be viewed in the graphical
display by selecting [39] Display Text 3 in
•
parameter 0-20 Display Line 1.1 Small,
•
parameter 0-21 Display Line 1.2 Small,
•
parameter 0-22 Display Line 1.3 Small,
•
parameter 0-23 Display Line 2 Large, or
•
parameter 0-24 Display Line 3 Large.
