Parameter Descriptions
3.7.9 5-9* Bus-Controlled
This parameter group selects digital and relay outputs via a
fieldbus setting.
5-90 Digital & Relay Bus Control
3 3
Range:
0 [0 - 2147483647] This parameter holds the state of the
*
Bit 0 Digital output terminal 27
Bit 1 Digital output terminal 29
Bit 2 Digital output terminal X 30/6
Bit 3 Digital output terminal X 30/7
Bit 4 Relay 1 output terminal
Bit 5 Relay 2 output terminal
Bit 6 Option B relay 1 output terminal
Bit 7 Option B relay 2 output terminal
Bit 8 Option B relay 3 output terminal
Bit 9–15 Reserved for future terminals
Bit 16 Option C relay 1 output terminal
Bit 17 Option C relay 2 output terminal
Bit 18 Option C relay 3 output terminal
Bit 19 Option C relay 4 output terminal
Bit 20 Option C relay 5 output terminal
Bit 21 Option C relay 6 output terminal
Bit 22 Option C relay 7 output terminal
Bit 23 Option C relay 8 output terminal
Bit 24–31 Reserved for future terminals
Table 3.22 Bus-controlled Digital Outputs and Relays
5-93 Pulse Out #27 Bus Control
Range:
0 % [0 -
*
100 %]
5-94 Pulse Out #27 Timeout Preset
Range:
0 % [0 -
*
100 %]
110
VLT
Function:
digital outputs and relays that is
controlled by bus.
A logical '1' indicates that the output is
high or active.
A logical '0' indicates that the output is
low or inactive.
Function:
Set the output frequency transferred to
output terminal 27 when the terminal is
configured as [45] Bus Controlled in
parameter 5-60 Terminal 27 Pulse Output
Variable.
Function:
Set the output frequency transferred to output
terminal 27 when the terminal is configured as
[48] Bus Ctrl Timeout in parameter 5-60 Terminal
27 Pulse Output Variable and a timeout is
detected.
