Electrical Installation

8.6.7 Electrical Installation, Control Cables

91 (L1)
3 Phase
92 (L2)
power
93 (L3)
input
95
DC bus 88 (-)
89 (+)
50 (+10 V OUT)
+10Vdc
0/-10Vdc -
53 (A IN)
+10Vdc
0/4-20 mA
0/-10Vdc -
54 (A IN)
+10Vdc
0/4-20 mA
55 (COM A IN)
12 (+24V OUT)
13 (+24V OUT)
18 (D IN)
19 (D IN)
20 (COM D IN)
27
*
29
32 (D IN)
33 (D IN)
*
37 (D IN)
Illustration 8.60 Diagram showing all electrical terminals without options.
A = analog, D = digital
Terminal 37 is used for Safe Stop. For instructions on Safe Stop installation please refer to the section Safe Stop Installation of the Design
Guide.
* Terminal 37 is not included in FC 301 (Except FC 301 A1, which includes Safe Stop).
Relay 2 and Terminal 29, have no function in FC 301.
Very long control cables and analogue signals may in rare cases and depending on installation result in 50/60 Hz earth
loops due to noise from mains supply cables. If this occurs, it may be necessary to break the screen or insert a 100 nF
capacitor between screen and chassis. The digital and analogue inputs and outputs must be connected separately to the
common inputs (terminal 20, 55, 39) of the frequency converter to avoid ground currents from both groups to affect other
groups. For example, switching on the digital input may disturb the analog input signal.
FC 300 Design Guide
PE
Switch Mode
Power Supply
10Vdc
15mA
+ -
S201
ON=0/4-20mA
S202
OFF=0/-10Vdc -
+10Vdc
P 5-00
24V (NPN)
0V (PNP)
24V (NPN)
0V (PNP)
24V (NPN)
(D IN/OUT)
0V (PNP)
24V
0V
24V (NPN)
(D IN/OUT)
0V (PNP)
24V
0V
24V (NPN)
0V (PNP)
24V (NPN)
0V (PNP)
®
MG.33.BD.02 - VLT is a registered Danfoss trademark
(U) 96
(V) 97
(W) 98
(PE) 99
24Vdc
(R+) 82
130/200mA
+ -
(R-) 81
relay1
* relay2
(COM A OUT) 39
(A OUT) 42
S801
ON=Terminated
OFF=Open
5V
S801
RS-485
(N RS-485) 69
Interface
(P RS-485) 68
(COM RS-485) 61
Motor
Brake
resistor
03
240Vac, 2A
02
01
06
240Vac, 2A
05
400Vac, 2A
04
Analog Output
0/4-20 mA
0V
RS-485
8 8
213
