5.2.8 Ordering Numbers: Harmonic Filters

Harmonic filters are used to reduce mains harmonics.
•
AHF 010: 10% current distortion
•
AHF 005: 5% current distortion
I Typical Motor Used [kW]
AHF,N
10 0.37 - 4
19 5.5 - 7.5
26 11
35 15 - 18.5
43 22
72 30 - 37
101 45 - 55
144 75
180 90
217 110
289 132
324 160
370 200
506 250
578 315
648 355
694 400
740 450
Table 5.1 380-415V, 50Hz
I Typical Motor Used [kW]
AHF,N
10 0.37 - 4
19 5.5 - 7.5
26 11
35 15 - 18.5
43 22
72 30 - 37
101 45 - 55
144 75
180 90
217 110
289 132
324 160
370 200
506 250
578 315
648 355
694 400
740 450
Table 5.2 380-415V, 60Hz
FC 300 Design Guide
Danfoss AHF 005
175G6600
175G6601
175G6602
175G6603
175G6604
175G6605
175G6606
175G6607
175G6608
175G6609
175G6610
175G6611
175G6688
175G6609 + 175G6610
2X 175G6610
2X 175G6611
175G6611 + 175G6688
2X 175G6688
Danfoss AHF 005
130B2540
130B2460
130B2461
130B2462
130B2463
130B2464
130B2465
130B2466
130B2467
130B2468
130B2469
130B2470
130B2471
130B2468 + 130B2469
2X 130B2469
2X 130B2470
130B2470 + 130B2471
2X 130B2471
®
