Options and Accessories
NC NC NC
1 2 3 4 5 6 7 8 9
LIVE LIVE
PART PART
WARNING
Do not combine 24/ 48V systems with high voltage
systems.
External 24V DC Supply
An external 24V DC supply can be installed for low-voltage supply to the control card and any option card installed. This
enables full operation of the LCP (including the parameter setting) without connection to mains.
External 24V DC supply specification:
Input voltage range
Max. input current
Average input current for FC 302
Max cable length
Input capacitance load
Power-up delay
The inputs are protected.
Terminal numbers:
Terminal 35: - external 24V DC supply.
Terminal 36: + external 24V DC supply.
Follow these steps:
1. Remove the LCP or Blind Cover
2. Remove the Terminal Cover
When MCB 107, 24V back-up option is supplying the control circuit, the internal 24V supply is automatically disconnected.
Illustration 10.7 Connection to 24V back-up supply on frame
sizes A2 and A3.
FC 300 Design Guide
NC
10 11 12 1 2 3 4 5
PELV PELV PELV
®
MG.33.BD.02 - VLT is a registered Danfoss trademark
NC NC
6 7 8 9 10 11 12 1 2
LIVE
PELV
PART
10.6 24V Back-Up Option MCB 107
3. Remove the Cable Decoupling Plate and the
plastic cover underneath
4. Insert the 24V DC Back-up External Supply Option
in the Option Slot
5. Mount the Cable Decoupling Plate
6. Attach the Terminal Cover and the LCP or Blind
Cover.
Illustration 10.8 Connection to 24V back-up supply on frame
sizes A5, B1, B2, C1 and C2.
NC NC NC
3 4 5 6 7 8 9 10 11
LIVE LIVE
PART PART
24V DC ±15 % (max. 37V in 10 sec.)
< 10uF
< 0.6 sec.
12
2.2A
0.9 A
75 m
10 10
