Electrical Installation
UL Compliance
Fuses or Circuit Breakers are mandatory to comply with NEC 2009. We recommend using a selection of the following
The fuses below are suitable for use on a circuit capable of delivering 100,000 Arms (symmetrical), 240V, or 480V, or 500V,
or 600V depending on the frequency converter voltage rating. With the proper fusing the drive Short Circuit Current Rating
(SCCR) is 100,000 Arms.
FC 300
Power
[kW]
0.25-0.37
0.55-1.1
1.5
2.2
3.0
3.7
5.5
7.5
11
15-18.5
8 8
22
30
37
Table 8.6 200-240V, Frame Sizes A, B, and C
FC 300
Power
[kW]
0.25-0.37
0.55-1.1
1.5
2.2
3.0
3.7
5.5
7.5
11
15-18.5
22
30
37
Table 8.7 200-240V, Frame Sizes A, B, and C
194
FC 300 Design Guide
Bussmann Bussmann
Type J
Type RK1 1)
KTN-R-05 JKS-05
KTN-R-10 JKS-10
KTN-R-15 JKS-15
KTN-R-20 JKS-20
KTN-R-25 JKS-25
KTN-R-30 JKS-30
KTN-R-50 KS-50
KTN-R-60 JKS-60
KTN-R-80 JKS-80
KTN-R-125 JKS-125
KTN-R-150 JKS-150
KTN-R-200 JKS-200
KTN-R-250 JKS-250
SIBA
Type RK1
5017906-005
5017906-010
5017906-016
5017906-020
5017906-025
5012406-032
5014006-050
5014006-063
5014006-080
2028220-125
2028220-150
2028220-200
2028220-250
MG.33.BD.02 - VLT
Recommended max. fuse
Bussmann Bussmann
Type T Type CC
JJN-05 FNQ-R-5
JJN-10 FNQ-R-10
JJN-15 FNQ-R-15
JJN-20 FNQ-R-20
JJN-25 FNQ-R-25
JJN-30 FNQ-R-30
JJN-50 -
JJN-60 -
JJN-80 -
JJN-125 -
JJN-150 -
JJN-200 -
JJN-250 -
Recommended max. fuse
Littel fuse
Type RK1
KLN-R-05
KLN-R-10
KLN-R-15
KLN-R-20
KLN-R-25
KLN-R-30
KLN-R-50
KLN-R-60
KLN-R-80
KLN-R-125
KLN-R-150
KLN-R-200
KLN-R-250
®
is a registered Danfoss trademark
Bussmann
Type CC
KTK-R-5
KTK-R-10
KTK-R-15
KTK-R-20
KTK-R-25
KTK-R-30
-
-
-
-
-
-
-
Ferraz-
Shawmut Shawmut
Type CC
Type RK1
ATM-R-05 A2K-05-R
ATM-R-10 A2K-10-R
ATM-R-15 A2K-15-R
ATM-R-20 A2K-20-R
ATM-R-25 A2K-25-R
ATM-R-30 A2K-30-R
- A2K-50-R
- A2K-60-R
- A2K-80-R
- A2K-125-R
- A2K-150-R
- A2K-200-R
- A2K-250-R
Bussmann
Type CC
LP-CC-5
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
-
-
-
-
-
-
-
Ferraz-
3)
