Electrical Installation
8 8
Illustration 8.39 Rectifier Cabinet, frame size F1, F2, F3 and F4
1) 24V DC, 5 A
T1 Output Taps
Temp Switch
106 104 105
2) Manual Motor Starters
3) 30 A Fuse Protected Power Terminals
4) Line
R S
L1 L2
176
FC 300 Design Guide
6
1
2
8
10
3
4
5
5)
6)
7)
8)
9)
T 10)
L3
MG.33.BD.02 - VLT
C J3
FUSE ONNECT
CH22 CH22 CH22 CH22 CH22 CH22
CTI25MB CTI25MB
FASTENER TORQUE: M10 19Nm (14 FT -LB)
FASTENER TORQUE: M10 19Nm (14 FT -LB)
+DC 89 +DC 89
Loadsharing
-DC +DC
88 89
Control Transformer Fuses (2 or 4 pieces). See fuse tables for part numbers
SMPS Fuse. See fuse tables for part numbers
Manual Motor Controller fuses (3 or 6 pieces). See fuse tables for part numbers
Line Fuses, F1 and F2 frame (3 pieces). See fuse tables for part numbers
30 Amp Fuse Protected Power fuses
®
