FC 300 Selection
Mains Supply 6 x 525- 690V AC, 12-Pulse
FC 302
High/ Normal Load
Typical Shaft output at 550V [kW]
Typical Shaft output at 575V [HP]
Typical Shaft output at 690V [kW]
Enclosure IP21, 54 without/ with options
cabinet
Output current
Continuous
(at 550V) [A]
Intermittent (60 sec overload)
(at 550V) [A]
Continuous
(at 575/ 690V) [A]
Intermittent (60 sec overload)
(at 575/ 690V) [A]
Continuous KVA
(at 550V) [KVA]
Continuous KVA
(at 575V) [KVA]
Continuous KVA
(at 690V) [KVA]
Max. input current
Continuous
(at 550V ) [A]
Continuous
(at 575V) [A]
Continuous
(at 690V) [A]
Max. cable size, motor [mm 2 (AWG 2) )]
Max. cable size,mains [mm 2 (AWG 2) )]
Max. cable size, brake [mm 2 (AWG 2) )
1
Max. external mains fuses [A]
Estimated power loss
4)
at 600V [W]
Estimated power loss
at 690V [W] 4)
F3/F4 Max added losses CB or Disconnect &
Contactor
Max panel options losses
Weight,
enclosure IP21, IP 54 [kg]
Weight, Rectifier Module [kg]
Weight, Inverter Module [kg]
Efficiency 4)
Output frequency
Heatsink overtemp. trip
Power card ambient trip
* High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s
FC 300 Design Guide
P630
HO NO
500 560
650 750
630 710
F10/F11
659 763
989 839
630 730
945 803
628 727
627 727
753 872
642 743
613 711
613 711
9201 10771
9674 11315
342 427
1004/ 1299
102
102
®
MG.33.BD.02 - VLT is a registered Danfoss trademark
P710
HO NO
560 670
750 950
710 800
F10/F11
763 889
1145 978
730 850
1095 935
727 847
727 847
872 1016
743 866
711 828
711 828
8x150
(8x300 mcm)
6x120
(6x250 mcm)
4x185
(4x350 mcm)
900
10416 12272
10965 12903
419 532
400
1004/ 1299
102
102
0.98
0-500Hz
85 °C
75 °C
P800
HO NO
670 750
950 1050
800 900
F10/F11
889 988
1334 1087
850 945
1275 1040
847 941
847 941
1016 1129
866 962
828 920
828 920
12260 13835
12890 14533
519 615
1004/ 1299
102
136
83
4 4
