11.11.5 Conversion Factor

The different attributes for each parameter can be seen in
the section on factory settings. Since a parameter value
can only be transferred as a whole number, a conversion
factor must be used to transfer decimals. Please refer to
the Parameters section.

11.11.6 Parameter Values

Standard Data Types
Standard data types are int16, int32, uint8, uint16 and
uint32. They are stored as 4x registers (40001 – 4FFFF). The
parameters are read using function 03HEX "Read Holding
Registers." Parameters are written using the function 6HEX
"Preset Single Register" for 1 register (16 bits), and the
function 10HEX "Preset Multiple Registers" for 2 registers
(32 bits). Readable sizes range from 1 register (16 bits) up
to 10 registers (20 characters).
Non standard Data Types
Non standard data types are text strings and are stored as
4x registers (40001 – 4FFFF). The parameters are read
using function 03HEX "Read Holding Registers" and written
using function 10HEX "Preset Multiple Registers." Readable
sizes range from 1 register (2 characters) up to 10 registers
(20 characters).

11.12 Danfoss FC Control Profile

11.12.1 Control Word According to FC
Profile (8-10 Control Profile = FC
profile)
Master-slave
CTW
Bit
no.:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FC 300 Design Guide
Bit
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
Explanation of the Control Bits
Bits 00/01
Bits 00 and 01 are used to choose between the four
reference values, which are pre-programmed in 3-10 Preset
Reference according to the following table:
Programmed ref.
value
1
2
3
4
Speed ref.
NOTE
Make a selection in 8-56 Preset Reference Select to define
how Bit 00/01 gates with the corresponding function on
the digital inputs.
Bit 02, DC brake:
Bit 02 = '0' leads to DC braking and stop. Set braking
current and duration in 2-01 DC Brake Current and 2-02 DC
Braking Time. Bit 02 = '1' leads to ramping.
Bit 03, Coasting:
Bit 03 = '0': The frequency converter immediately "lets go"
of the motor, (the output transistors are "shut off") and it
coasts to a standstill. Bit 03 = '1': The frequency converter
starts the motor if the other starting conditions are met.
®
MG.33.BD.02 - VLT
is a registered Danfoss trademark
Bit value = 0
Bit value = 1
Reference value
external selection lsb
Reference value
external selection msb
DC brake
Ramp
Coasting
No coasting
Quick stop
Ramp
Hold output
use ramp
frequency
Ramp stop
Start
No function
Reset
No function
Jog
Ramp 1
Ramp 2
Data invalid
Data valid
No function
Relay 01 active
No function
Relay 02 active
Parameter set-up
selection lsb
Parameter set-up
selection msb
No function
Reverse
Parameter
Bit 01
3-10 Preset
0
Reference [0]
3-10 Preset
0
Reference [1]
3-10 Preset
1
Reference [2]
3-10 Preset
1
Reference [3]
Bit 00
0
11
11
1
0
1
267
