Mechanical Installation - ...
Be aware that the power cables are heavy and hard to
bend. Consider the optimum position of the frequency
converter for ensuring easy installation of the cables.
NOTE
All D frames are available with standard input terminals or disconnect switch. All terminal dimensions can be found in the
following table.
Frame size
D1
A 277 (10.9)
B 227 (8.9)
C 173 (6.8)
D 179 (7.0)
E 370 (14.6)
7 7
F 300 (11.8)
G 222 (8.7)
H 139 (5.4)
I 55 (2.2)
J 354 (13.9)
K 284 (11.2)
L 334 (13.1)
M 250 (9.8)
N 167 (6.6)
O 261 (10.3)
P 170 (6.7)
Q 120 (4.7)
R 256 (10.1)
S 308 (12.1)
T 252 (9.9)
U 196 (7.7)
V 260 (10.2)
Table 7.1 Cable positions as shown in drawings above. Dimensions in mm (inch).
136
IP21 (NEMA 1) / IP54 IP00 / Chassis
(NEMA 12)
Frame size Frame size
D2 D3
379 (14.9) 119 (4.7)
326 (12.8) 68 (2.7)
273 (10.8) 15 (0.6)
279 (11.0) 20.7 (0.8)
370 (14.6) 363 (14.3)
300 (11.8) 293 (11.5)
226 (8.9) 215 (8.4)
142 (5.6) 131 (5.2)
59 (2.3) 48 (1.9)
361 (14.2) 347 (13.6)
277 (10.9) 277 (10.9)
334 (13.1) 326 (12.8)
250 (9.8) 243 (9.6)
167 (6.6) 159 (6.3)
260 (10.3) 261 (10.3)
169 (6.7) 170 (6.7)
120 (4.7) 120 (4.7)
350 (13.8) 98 (3.8)
332 (13.0) 301 (11.8)
262 (10.3) 245 (9.6)
192 (7.6) 189 (7.4)
273 (10.7) 260 (10.2)
MG.33.BD.02 - VLT
FC 300 Design Guide
Frame size
D4
122 (4.8)
68 (2.7)
16 (0.6)
22 (0.8)
363 (14.3)
293 (11.5)
218 (8.6)
135 (5.3)
51 (2.0)
354 (13.9)
270 (10.6)
326 (12.8)
243 (9.6)
159 (6.3)
261 (10.3)
170 (6.7)
120 (4.7)
93 (3.7)
324 (12.8)
255 (10.0)
185 (7.3)
273 (10.7)
®
