Electrical Installation
Enclosure FC 300 Power
Size
A1
A2
A3
B3
B4
C3
C4
A4
A5
B1
8 8
B2
C1
C2
D
E
F
Table 8.3 380-500V, Frame Sizes A, B, C, D, E, and F
192
FC 300 Design Guide
Recommended
fuse size
[kW]
0.37-1.5 gG-10
0.37-4.0 gG-10 (0.37-3)
gG-16 (4)
5.5-7.5 gG-16
11-15 gG-40
18.5-30 gG-50 (18.5)
gG-63 (22)
gG-80 (30)
37-45 gG-100 (37)
gG-160 (45)
55-75 aR-200 (55)
aR-250 (75)
0.37-4 gG-10 (0.37-3)
gG-16 (4)
0.37-7.5 gG-10 (0.37-3)
gG-16 (4-7.5)
11-15 gG-40
18.5-22 gG-50 (18.5)
gG-63 (22)
30-45 gG-80 (30)
gG-100 (37)
gG-160 (45)
55-75 aR-200 (55)
aR-250 (75)
gG-300 (90)
gG-350 (110)
90-200 gG-400 (132)
gG-500 (160)
gG-630 (200)
aR-700 (250)
250-400
aR-900 (315-400)
aR-1600 (450-500)
450-800 aR-2000 (560-630)
aR-2500 (710-800)
MG.33.BD.02 - VLT
Recommended Recommended circuit
Max. fuse
gG-25
gG-25
gG-32
gG-63
gG-125
gG-150 (37)
gG-160 (45)
aR-250
gG-32
gG-32
gG-80
gG-100
gG-160
aR-250
gG-300 (90)
gG-350 (110)
gG-400 (132)
gG-500 (160)
gG-630 (200)
aR-700 (250)
aR-900 (315-400)
aR-1600 (450-500)
aR-2000 (560-630)
aR-2500 (710-800)
®
is a registered Danfoss trademark
Max trip level
breaker
Moeller [A]
PKZM0-16 16
PKZM0-25 25
PKZM0-25 25
PKZM4-50 50
NZMB1-A100 100
NZMB2-A200 150
NZMB2-A250 250
PKZM0-25 25
PKZM0-25 25
PKZM4-63 63
NZMB1-A100 100
NZMB2-A200 160
NZMB2-A250 250
- -
- -
- -
