Introduction to FC 300

3 Introduction to FC 300

3.1 Product Overview

Frame size depends on enclosure type, power range and mains voltage
Frame size A1*
Enclosure IP 20/21
protection
NEM Chassis/Type 1
A
High overload 0.25 – 1.5kW (200-240V)
rated power - 0.37 – 1.5kW (380-480V)
160% overload
torque
Frame size B1
Enclosure IP 21/55/66
protection
NEM Type 1/Type 12
A
High overload 5.5-7.5kW (200-240V)
rated power - 11-15kW (380-480/500V)
160% overload 11-15kW (525-600V)
torque
Frame size C1
Enclosure IP 21/55/66
protection
NEM Type 1/Type 12
A
High overload 15-22kW (200-240V)
rated power - 30-45kW (380-480/500V)
160% overload 30-45kW (525-600V)
torque
* A1, A2 and A3 are bookstyle enclosures. All other sizes are compact enclosures.
FC 300 Design Guide
A2* A3*
20/21
Chassis/ Type 1 Chassis/ Type 1
0.25-3kW (200–240V) 3.7kW (200-240V)
0.37-4.0kW (380-480/ 5.5-7.5kW (380-480/500V)
500V) 0.75-7.5kW (525-600V )
B2 B3
21/55/66
Type 1/Type 12 Chassis
11kW (200-250V) 5.5-7.5kW (200-240V)
18.5-22kW 11-15kW (380-480/500V)
(380-480/500V) 11-15kW (525-600V)
18.5-22kW (525-600V)
11-22kW (525-690V)
C2 C3
21/55/66
Type 1/Type 12 Chassis
30-37kW (200-240V) 18.5-22kW (200-240V)
55-75kW (380-480/500V) 37-45kW (380-480/500V)
55-90kW (525-600V) 37-45kW (525-600V)
30-75kW (525-690V)
®
MG.33.BD.02 - VLT is a registered Danfoss trademark
A4
20/21 55/66
Type 12
0.25-3kW (200–240V)
0.37-4.0kW (380-480/500V)
B4
20 20
Chassis
11-15kW (200-240V)
18.5-30kW (380-480/500V)
18.5-30kW (525-600V)
C4
20 20
Chassis
30-37kW (200-240V)
55-75kW (380-480/500V)
55-90kW (525-600V)
3
A5
55/66
Type 12
0.25-3.7kW (200-240V)
0.37-7.5kW (380-480/500V)
0.75 -7.5kW (525-600V)
