How to Order
FC 302 - Mains: 525-600V (T6) - 10% Duty Cycle
FC 302 P R R
m (HO) min
T6 [kW] [Ω]
PK75 0.75 620
P1K1 1.1 550
P1K5 1.5 380
P2K2 2.2 270
P3K0 3 189
P4K0 4 135
P5K5 5.5 99
P7K5 7.5 72
P11K 11 40
P15K 15 36
P18K 18.5 27
P22K 22 22.5
P30K 30 18
P37K 37 13.5
P45K 45 10.8
P55K 55 8.8
P75K 75 6.6
P90K 90 4.7
P110 110 4.7
P132 132 4.2
P160 160 3.4
P200 200 2.7
P250 250 2.2
P315 315 1.7
P355 355 1.6
P400 400 1.4
P450 450 1.2
P500 500 1.2
P560 560 1.2
P670 670 1.2
P750 750 1.2
P850 850 1.2
P1M0 1000 1.2
P1M1 1100 1.2
FC 300 Design Guide
R P
br, nom rec br avg
[Ω] [Ω] [kW]
904 620 0.1
613 620 0.1
447 425 0.1
301 310 0.3
218 210 0.3
162 150 0.4
116 110 0.6
84.5 80 0.9
57 40 2
41.3 40 2
33.2 30 2.8
27.6 25 3.5
21.6 20 4
17.3 15 4.8
14.2 12 5.5
11.6 9.8 15
8.4 7.3 13
7 4.7 18
5.8 4.7 18
4.8 4.7 18
4 3.8 22
3.2 5.2 / 2 = 2.6 36 x 2 = 72
2.5 5.2 / 2 = 2.6 36 x 2 = 72
2
1.8
1.6
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
®
