7.2.6 Terminal Locations, F8-F13 - 12-Pulse

The 12-pulse F enclosures have six different sizes, F8, F9, F10, F11, F12 and F13 The F8, F10 and F12 consist of an inverter
cabinet on the right and rectifier cabinet on the left. The F9, F11 and F13 have an additional options cabinet left of the
rectifier cabinet. The F9 is an F8 with an additional options cabinet. The F11 is an F10 with an additional options cabinet.
The F13 is an F12 with an additional options cabinet.
Terminal locations - Inverter and Rectifier Frame size F8 and F9
7 7
Illustration 7.33 Terminal locations - Inverter and Rectifier Cabinet - F8 and F9 (front, left and right side view). The gland plate is 42mm
below .0 level.
1) Earth ground bar
146
FC 300 Design Guide
239.6 [ 9.43 ]
R2/L12 91-1 S2/L22 92-1 T2/L32
160.0 [ 6.30 ]
R1/L11 91 S1/L21 92 T1/L31 93
56.6 [ 2.23 ]
0.0 [ 0.00 ]
®
MG.33.BD.02 - VLT is a registered Danfoss trademark
U/T1 96 V/T2 97 W/T3 98
93-1
1
