Danfoss VLT AutomationDrive Design Manual page 187

Electrical Installation
8 8
Illustration 8.47 Inverter Cabinet, frame size F12 and F13
1) External Temperature Monitoring
2) AUX Relay
01 02
04 05
3) NAMUR
4) AUX Fan
100 101 102 103
L1 L2
5) Brake
-R +R
81 82
186
FC 300 Design Guide
3
7
4, 8, 9
5
6
03
06
L1 L2
MG.33.BD.02 - VLT
1
2
FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97
6) Motor
U V
96 97
T1 T2
7) NAMUR Fuse. See fuse tables for part numbers
8) Fan Fuses. See fuse tables for part numbers
9) SMPS Fuses. See fuse tables for part numbers
®
