Ordering Numbers: Brake Resistors 40 - Danfoss VLT AutomationDrive Design Manual

How to Order
FC 302 - Mains: 525-690V (T7) - 10% Duty Cycle
FC 302
T7
P400
P500
P560
P630
P710
P800
5 5
P900
P1M1
P1M2

5.2.6 Ordering Numbers: Brake Resistors 40%

FC 301 - Mains: 200-240V (T2) - 40% Duty Cycle
FC 301
T2
PK25
PK37
PK55
PK75
P1K1
P1K5
P2K2
P3K0
P3K7
FC 302 - Mains: 200-240V (T2) - 40% Duty Cycle
FC 302
T2
PK25
PK37
PK55
PK75
P1K1
P1K5
P2K2
P3K0
P3K7
106
FC 300 Design Guide
P R R R
m (HO) min br, nom rec
[kW] [Ω] [Ω]
400 1.9 2.2 4.2 / 2 = 2.1
500 1.5 1.7 4.2 / 2 = 2.1
560 1.4 1.5 4.2 / 2 = 2.1
630 1.2 1.4 4.2 / 2 = 2.1
710 1.2 1.3 4.2 / 2 = 2.1
800 1.2 1.3 4.2 / 2 = 2.1
900 1.2 1.3 4.2 / 2 = 2.1
1000 1.2 1.3 4.2 / 2 = 2.1
1200 1.2 1.3 4.2 / 2 = 2.1
P R R
m (HO) min br, nom
[kW]
[Ω] [Ω]
0.25 368 408
0.37 248 276
0.55 166 185
0.75 121 135
1.1 81 91.4
1.5 58.5 66.2
2.2 40.2 44.6
3 29.1 32.4
3.7 22.5 25.9
P R R
m (HO) min br, nom
[kW]
[Ω] [Ω]
0.25 382 467
0.37 279 315
0.55 189 211
0.75 130 154
1.1 81 104
1.5 58.5 75.7
2.2 45 51
3 31.5 37
3.7 22.5 29.6
MG.33.BD.02 - VLT
P Order no.
br avg
[Ω] [kW] 175Uxxxx
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
R P Order
rec br avg
no.
[kW] 175Uxxxx
[Ω]
425 0.43 1941
310 0.80 1942
210 1.35 1943
145 0.26 1920
90 0.43 1921
65 0.80 1922
50 1.00 1923
35 1.35 1924
25 3.00 1925
R P Order
rec br avg
no.
[kW] 175Uxxxx
[Ω]
425 0.43 1941
310 0.80 1942
210 1.35 1943
145 0.26 1920
90 0.43 1921
65 0.80 1922
50 1.00 1923
35 1.35 1924
25 3.00 1925
®
is a registered Danfoss trademark
Period Cable cross
section
[s] [mm2]
300 2 x 120
300 2 x 120
300 2 x 120
300 2 x 120
300 2 x 120
300 2 x 120
300 2 x 120
300 2 x 120
300 2 x 120
Period Cable cross Therm.
2 relay
section *
[s] [mm2] [A]
120 1.5 1
120 1.5 1.6
120 1.5 2.5
120 1.5 1.3
120 1.5 2.2
120 1.5 3.5
120 1.5 4.5
120 1.5 6.2
120 1.5 11
Period Cable cross Therm.
relay
section 2 *
[s] [mm2] [A]
120 1.5 1.0
120 1.5 1.6
120 1.5 2.5
120 1.5 1.3
120 1.5 2.2
120 1.5 3.5
120 1.5 4.5
120 1.5 6.2
120 1.5 11
Max. brake
torque with
R *
rec
[%]
150 (150)
123 (150)
118 (150)
98 (150)
87 (140)
77 (124)
68 (110)
61 (99)
51 (83)
Max. brake
torque with
R *
rec
[%]
154 (160)
142 (160)
141 (160)
149 (160)
160 (160)
160 (160)
143 (160)
148 (160)
160 (160)
Max. brake
torque with
R *
rec
[%]
160 (160)
160 (160)
160 (160)
160 (160)
160 (160)
160 (160)
160 (160)
160 (160)
160 (160)
