1 How to Read this Design Guide

This Design Guide will introduce all aspects of your FC 300.
Available literature for FC 300
- The VLT AutomationDrive Operating Instructions
MG.33.AX.YY provide the neccessary information
for getting the drive up and running.
- The VLT AutomationDrive High Power Operating
Instructions MG.33.UX.YY
- The VLT AutomationDrive Design Guide MG.
33.BX.YY entails all technical information about
the drive and customer design and applications.
- The VLT AutomationDrive Programming Guide
MG.33.MX.YY provides information on how to
programme and includes complete parameter
descriptions.
- The VLT AutomationDrive Profibus Operating
Instructions MG.33.CX.YY provide the information
required for controlling, monitoring and
programming the drive via a Profibus fieldbus.
- The VLT AutomationDrive DeviceNet Operating
Instructions MG.33.DX.YY provide the information
required for controlling, monitoring and
programming the drive via a DeviceNet fieldbus.
X = Revision number
YY = Language code
Danfoss Drives technical literature is also available online
at www.danfoss.com/BusinessAreas/DrivesSolutions/
Documentations/Technical+Documentation.

1.1.1 Symbols

Symbols used in this guide.
NOTE
Indicates something to be noted by the reader.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury or
equipment damage.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
FC 300 Design Guide
*

1.1.2 Abbreviations

Alternating current
American wire gauge
Ampere/AMP
Automatic Motor Adaptation
Current limit
Degrees Celsius
Direct current
Drive Dependent
Electro Magnetic Compatibility
Electronic Thermal Relay
frequency converter
Gram
Hertz
Horsepower
Kilohertz
Local Control Panel
Meter
Millihenry Inductance
Milliampere
Millisecond
Minute
Motion Control Tool
Nanofarad
Newton Meters
Nominal motor current
Nominal motor frequency
Nominal motor power
Nominal motor voltage
Parameter
Protective Extra Low Voltage
Printed Circuit Board
Rated Inverter Output Current
Revolutions Per Minute
Regenerative terminals
Second
Synchronous Motor Speed
Torque limit
Volts
The maximum output current
The rated output current supplied by the
frequency converter
®
MG.33.BD.02 - VLT is a registered Danfoss trademark
Indicates default setting
1
AC
AWG
A
AMA
I
LIM
°C
DC
D-TYPE
EMC
ETR
FC
g
Hz
hp
kHz
LCP
m
mH
mA
ms
min
MCT
nF
Nm
I
M,N
f
M,N
P
M,N
U
M,N
par.
PELV
PCB
I
INV
RPM
Regen
sec.
n
s
T
LIM
V
I
VLT,MAX
I
VLT,N
7
