Options and Accessories

10.2.2 Digital Inputs - Terminal X30/1-4:

Digital input:
Number of digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic'0' PNP (GND = 0V)
Voltage level, logic'1' PNP (GND = 0V)
Voltage level, logic '0' NPN (GND = 24V)
Voltage level, logic '1' NPN (GND = 24V)
Maximum voltage on input
Pulse frequency range
Duty cycle, min. pulse width
Input impedance

10.2.3 Analog Inputs - Terminal X30/11, 12:

Analog input:
Number of analog inputs
Terminal number
Modes
Voltage level
Input impedance
Max. voltage
10 10
Resolution for analog inputs
Accuracy of analog inputs
Bandwidth

10.2.4 Digital Outputs - Terminal X30/6, 7:

Digital output:
Number of digital outputs
Terminal number
Voltage level at digital/frequency output
Max. output current
Max. load
Max. capacitive load
Minimum output frequency
Maximum output frequency
Accuracy of frequency output

10.2.5 Analog Output - Terminal X30/8:

Analog output:
Number of analog outputs
Terminal number
Current range at analog output
Max. load GND - analog output
Accuracy on analog output
Resolution on analog output
238
FC 300 Design Guide
®
MG.33.BD.02 - VLT is a registered Danfoss trademark
3
X30.2, X30.3, X30.4
PNP or NPN
0 - 24V DC
< 5V DC
> 10V DC
< 14V DC
> 19V DC
28 V continous
0 - 110 kHz
4.5 ms
> 2 kΩ
2
X30.11, X30.12
Voltage
0 - 10V
> 10kΩ
20V
10 bit (+ sign)
Max. error 0.5% of full scale
FC 301: 20Hz/ FC 302: 100Hz
2
X30.6, X30.7
0 - 24V
40mA
≥ 600 Ω
< 10nF
0Hz
≤ 32kHz
Max. error: 0.1 % of full scale
1
X30.8
0 - 20mA
500Ω
Max. error: 0.5 % of full scale
12 bit
