Danfoss VLT AutomationDrive Design Manual page 17

Introduction to FC 300
Frame size
3 3
Enclosure IP
protection
NEMA
High overload rated
power - 160%
overload torque
Frame size
Enclosure IP
protection
NEMA
High overload rated
power - 160%
overload torque
NOTE
The F frames are available with or without options cabinet. The F1 and F2 consist of an inverter cabinet on the right and
rectifier cabinet on the left. The F3 and F4 have an additional options cabinet left of the rectifier cabinet. The F3 is an F1
with an additional options cabinet. The F4 is an F2 with an additional options cabinet.
12-Pulse Units
Frame size
IP
NEMA
High overload rated
power - 160% overload
torque
NOTE
The F frames are available with or without options cabinet. The F8, F10 and F12 consist of an inverter cabinet on the right
and rectifier cabinet on the left. The F9, F11 and F13 have an additional options cabinet left of the rectifier cabinet. The F9
is an F8 with an additional options cabinet. The F11 is an F10 with an additional options cabinet. The F13 is an F12 with an
additional options cabinet.
16
FC 300 Design Guide
D1 D2
21/54
Type 1/ Type 12
90-110kW at 400V 132-200kW at 400V
(380-/ 500V) (380-/ 500V)
37-132kW at 690V 160-315kW at 690V
(525-690V) (525-690V)
E1 E2
21/54
Type 1/ Type 12
250-400kW at 400V 250-400kW at 400V
(380-/500V) (380-/500V)
355-560kW at 690V 355-560kW at 690V
(525-690V) (525-690V)
F8 F9
21, 54 21, 54
Type 1/Type 12 Type 1/Type 12
F9 F8
250 - 400kW 250 - 400kW
(380 - 500V) (380 - 500V)
355 - 560kW 355 - 56kW
(525-690V) (525-690V)
MG.33.BD.02 - VLT
D3
21/54
Type 1/ Type 12 Chassis
90-110kW at 400V
(380-/500V)
37-132kW at 690V
(525-690V)
F1/F3
F3 F1
00
Chassis Type 1/ Type 12
450 - 630kW at 400V
(380 - /500V)
630 - 800kW at 690V
(525-690V)
F10 F11
21, 54 21, 54
Type 1/Type 12 Type 1/Type 12
F11
F10
450 - 630kW 450 - 630kW
(380 - 500V) (380 - 500V)
630 - 800kW 630 - 800kW
(525-690V) (525-690V)
®
is a registered Danfoss trademark
D4
00 00
Chassis
132-200kW at 400V
(380-/ 500V)
160-315kW at 690V
(525-690V)
F2/ F4
F4 F3
21/54 21/54
Type 1/ Type 12
710 - 800kW at 400V
(380 - / 500V)
900 - 1000kW at 690V
(525-690V)
F12
21, 54
Type 1/Type 12
F13
F12
710 - 800kW
(380 - 500V)
900 - 1200kW
(525-690V)
F13
21, 54
Type 1/Type 12
710 - 800kW
(380 - 500V)
900 - 1200kW
(525-690V)
