Electrical Installation
Illustration 8.44 Rectifier and Inverter Cabinet, frame size F8 and F9
1) 12-pulse rectifier module
2) Ground / Earth PE Terminals
3) Line / Fuses
R1 S1 T1
L1-1 L2-1 L3-1
91-1 92-1 93-1
4) Line / Fuses
R2 S2 T2
L2-1 L2-2 L3-2
91-2 92-2 93-2
FC 300 Design Guide
10
1
2
5) Motor connection
U V W
T1 T2 T3
96 97 98
6) Brake Terminals
-R +R
81 82
7) Inverter Module
8) SCR Enable / Disable
9) Relay 1 Relay 2
01 02 03 04
10) Auxillary Fan
104 106
®
MG.33.BD.02 - VLT is a registered Danfoss trademark
9
8
7
6
5
4
3
05 06
8 8
