Options and Accessories
Set-up example
1-00 Configuration Mode
1-01 Motor Control Principle
1-10 Motor Construction
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
AMA is not possible on PM motors
1-30 Stator Resistance (Rs)
30-80 d-axis Inductance (Ld)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-41 Motor Angle Offset
17-50 Poles
17-51 Input Voltage
17-52 Input Frequency
17-53 Transformation Ratio
17-59 Resolver Interface
Table 10.1 Adjust following parameters

10.5 Relay Option MCB 105

The MCB 105 option includes 3 pieces of SPDT contacts and must be fitted into option slot B.
Electrical Data:
Max terminal load (AC-1) 1) (Resistive load)
1)
Max terminal load (AC-15 )
1)
Max terminal load (DC-1) (Resistive load)
1)
Max terminal load (DC-13) (Inductive load)
Min terminal load (DC)
Max switching rate at rated load/min load
1) IEC 947 part 4 and 5
FC 300 Design Guide
Speed closed loop [1]
Flux with feedback [3]
PM, non salient SPM [1]
Nameplate
Nameplate
Nameplate
Motor data sheet
Motor data sheet (mH)
Motor data sheet
Motor data sheet
Motor data sheet (Usually zero)
Resolver data sheet
Resolver data sheet
Resolver data sheet
Resolver data sheet
Enabled [1]
(Inductive load @ cosφ 0.4)
®
MG.33.BD.02 - VLT is a registered Danfoss trademark
In this example a Permanent Magnet (PM) Motor is used
with resolver as speed feedback. A PM motor must usually
operate in flux mode.
Wiring:
The max cable length is 150m when a twisted pair type of
cable is used.
NOTE
Resolver cables must be screened and separated from the
motor cables.
NOTE
The screen of the resolver cable must be correctly
connected to the de-coupling plate and connected to
chassis (earth) on the motor side.
NOTE
Always use screened motor cables and brake chopper
cables.
10 10
240V AC 2A
240 V AC 0.2A
24V DC 1 A
24V DC 0.1 A
5V 10mA
-1 -1
6 min /20 sec
241
