How to Order

5 How to Order

5.1 Ordering Form

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
F C -
Table 5.1 Type Code String
Product groups 1-3
Frequency converter series 4-6
Generation code
7
Power rating
8-10
Phases
11
Mains Voltage
12
Enclosure
13-15
Enclosure type
Enclosure class
Control supply voltage
Hardware configuration
16-23
RFI filter/Low Harmonic 16-17
Drive/12-pulse
Brake
18
Display (LCP)
19
Coating PCB
20
Mains option
21
Adaptation A
22
Adaptation B
23
Software release
24-27
Software language 28
A options 29-30
B options 31-32
C0 options, MCO 33-34
C1 options 35
C option software 36-37
D options
38-39
Table 5.2 Type Code Example for Ordering a Frequency
Converter
®
VLT AutomationDrive FC 300 Design Guide 90-1200 kW
T
MG34S202 - Rev. 2013-08-19
21 22 23 24 25 26 27 28 29 30
X X S X X X X A
Not all choices/options are available for each FC 302
variant. To verify if the appropriate version is available,
consult the drive configurator on the Internet.

5.1.1 Drive Configurator

It is possible to design an FC 300 frequency converter
according to the application requirements by using the
ordering number system shown in Table 5.1 and Table 5.2.
For the FC 300 series, order standard frequency converters
and frequency converters with integral options by sending
a type code string describing the product to the local
Danfoss sales office, for example:
FC-302N132T5E20H4BGCXXXSXXXXA0BXCXXXXD0
The meaning of the characters in the string are defined in
Table 5.3. Additional detail is provided for each frequency
converter in the can be located in the pages containing
the ordering numbers in this chapter. In the example
above, a Profibus DP V1 and a 24 V back-up option is
included in the frequency converter.
Use the drive configurator to configure the appropriate
drive for the right application. The drive configurator
automatically generates an 8-digit sales number to be
delivered to the local sales office.
It is also possible to establish a project list with several
products and send it to a Danfoss sales representative.
The drive configurator can be found on the global Internet
site: www.danfoss.com/drives.
Frequency converters are delivered automatically with a
language package relevant to the region from which they
are ordered. Four regional language packages cover the
following languages:
Language Package 1
English, German, French, Danish, Dutch, Spanish, Swedish,
Italian, and Finnish.
31 32 33 34 35 36 37 38 39
B C D
5 5
