How to Order
Description Pos Possible choice
Product group 1-3 302: FC 302
Drive series 4-6 FC 302
Power rating 8-10 250-560 kW
Phases 11 Three phases (T)
Mains voltage 11-12 T 5: 380-500 V AC
T 7: 525-690 V AC
Enclosure 13-15 E00: IP00 (chassis - for installation in
an external enclosure)
C00: IP00/Chassis w/ stainless steel
back channel
E21: IP21 (NEMA 1)
E54: IP54 (NEMA 12)
E2M: IP21 (NEMA 1) with mains
shield
E5M: IP54 (NEMA 12) with mains
shield
RFI filter 16-17 H2: RFI filter, class A2 (standard)
H4: RFI filter class A1
B2: 12-pulse drive with RFI filter,
class A2
B4: 12-pulse drive with RFI filter,
class A1
N2: LHD with RFI filter, class A2
N4: LHD with RFI filter, class A1
Brake 18 B: Brake IGBT mounted
X: No brake IGBT
R: Regeneration terminals
S: Brake + regeneration
Display 19 G: Graphical Local Control Panel LCP
N: Numerical Local Control Panel
(LCP)
X: No Local Control Pane
Coating PCB 20 C: Coated PCB
Mains option 21 X: No mains option
3: Mains disconnect and Fuse
5: Mains disconnect, Fuse and Load
sharing
7: Fuse
A: Fuse and Load sharing
D: Load sharing
Adaptation 22 X: Standard cable entries
Adaptation 23 X: No adaptation
Software 24-27 Actual software
release
Software 28
language
Table 5.4 Ordering Type Code for E-frame Frequency Converters
1)
Available for 380-480/500 V only.
2)
Consult the factory for applications requiring maritime certification.
®
VLT AutomationDrive FC 300 Design Guide 90-1200 kW
Description
Product group
Power rating
Phases
Mains voltage
Enclosure
1)
MG34S202 - Rev. 2013-08-19
Pos Possible choice
1-6 FC 302
8-10 450-1200 kW
11 Three phases (T)
11-12 T 5: 380-500 V AC
T 7: 525-690 V AC
13-15 C21: IP21/NEMA Type 1 with stainless
steel back channel
C54: IP54/Type 12 Stainless steel back
channel
E21: IP 21/ NEMA Type 1
E54: IP 54/ NEMA Type 12
L2X: IP21/NEMA 1 with cabinet light &
IEC 230 V power outlet
L5X: IP54/NEMA 12 with cabinet light &
IEC 230 V power outlet
L2A: IP21/NEMA 1 with cabinet light &
NAM 115 V power outlet
L5A: IP54/NEMA 12 with cabinet light &
NAM 115 V power outlet
H21: IP21 with space heater and
thermostat
H54: IP54 with space heater and
thermostat
R2X: IP21/NEMA1 with space heater,
thermostat, light & IEC 230 V outlet
R5X: IP54/NEMA12 with space heater,
thermostat, light & IEC 230 V outlet
R2A: IP21/NEMA1 with space heater,
thermostat, light, & NAM 115 V outlet
R5A: IP54/NEMA12 with space heater,
thermostat, light, & NAM 115 V outlet
