Danfoss VLT AutomationDrive FC 300 Design Manual page 82

How to Order
Language Package 2
English, German, Chinese, Korean, Japanese, Thai,
Traditional Chinese, and Bahasa Indonesian.
Language Package 3
English, German, Slovenian, Bulgarian, Serbian, Romanian,
Hungarian, Czech, and Russian.
Language Package 4
English, German, Spanish, English US, Greek, Brazilian
Portuguese, Turkish, and Polish.
To order drives with a different language package, contact
the local Danfoss sales office.
5 5
Description
Product group
Generation
Code
Power rating
Phases
Mains voltage
Enclosure
RFI filter
Brake
Display
Coating PCB
80
VLT
Pos Possible choice
1-6 302: FC 302
7 N
8-10 55-315 kW
11 Three phases (T)
11-12 T 5: 380-500 V AC
T 7: 525-690 V AC
13-15 E20: IP20 (chassis - for installation in
an external enclosure)
E2S: IP20/chassis - D3h Frame
E21: IP21 (NEMA 1)
E2D: IP21/Type-1 D1h Frame
E54: IP54 (NEMA 12)
E5D: IP54/Type-12 D1h Frame
E2M: IP21 (NEMA 1) with mains
shield
E5M: IP54 (NEMA 12) with mains
shield
C20: IP20 (chassis) + stainless steel
back channel
C2S: IP20/chassis with stainless steel
back channel - D3h Frame
H21: IP21 (NEMA 1) + heater
H54: IP54 (NEMA 12) + heater
16-17 H2: RFI filter, class A2 (standard)
1)
H4: RFI filter class A1
18 X: No brake IGBT
B: Brake IGBT mounted
R: Regeneration terminals
S: Brake + regeneration (IP20 only)
19 G: Graphical Local Control Panel LCP
N: Numerical Local Control Panel
(LCP)
X: No Local Control Panel
20 C: Coated PCB
R: Coated PCB + ruggedized
®
AutomationDrive FC 300 Design Guide 90-1200 kW
Description
Mains option
Adaptation
Adaptation
Software
release
Software
language
Table 5.3 Ordering Type Code for D-frame Frequency
Converters
1) Available for all D-frames.
MG34S202 - Rev. 2013-08-19
Pos Possible choice
21 X: No mains option
3: Mains disconnect and fuse
4: Mains contactor + fuses
7: Fuse
A: Fuse and load sharing (IP20 only)
D: Load share terminals (IP20 only)
E: Mains disconnect + contactor +
fuses
J: Circuit breaker + fuses
22 X: Standard cable entries
23 X: No adaptation
Q: Heat sink access panel
24-27 Actual software
28
