Electrical Installation
Terminal Locations - D8h
Take the following position of the terminals into consideration when designing the cable access.
A-A
7 7
Illustration 7.14 Terminal Locations, D8h with Contactor Option
1 TB6 Terminal block for contactor
2 Motor Terminals
3 Earth/Ground Terminals
Table 7.12 Legend to Illustration 7.14
172
®
VLT AutomationDrive FC 300 Design Guide 90-1200 kW
5
898
[ 35.3 ]
4
3
418
[ 16.5 ]
378
[ 14.9 ]
0
0 [ ]
R
S
MG34S202 - Rev. 2013-08-19
A
B
1
521
[ 20.5 ]
401
[ 15.8 ]
B
A
V
U
T
W
4 Brake Terminals
5 Mains Terminals
B-B
2
