Electrical Installation

7.3.2 Mains Disconnects, 12-Pulse

Frame size
380-500 V
F9
F9
F9
F9
F11
F11
F11
F11
F13
F13
525-690 V
F9
F9
F9
F9
F11
F11
F11
F13
F13
F13
Table 7.60 Mains Disconnects, 12-Pulse Frequency Converters

7.3.3 Mains Contactors

NOTICE
Customer-supplied 230 V supply is required for mains contactors.
Frame size
D6h
D8h
Table 7.61 D-frame Contactors
Frame size
F3 P450-P500 380-500 V & P630-P800 525-690 V
F3
F3
F4
F4 P710-P800 380-500 V & P1M2 525-690 V
Table 7.62 F-frame Contactors
®
VLT AutomationDrive FC 300 Design Guide 90-1200 kW
Power
P250
P315
P355
P400
P450
P500
P560
P630
P710
P800
P355
P400
P500
P560
P630
P710
P800
P900
P1M0
P1M2
Power & Voltage
N90K-N132 380-500 V
N110-N160 380-480 V
N55-N132 525-690 V
N75-N160 525-690 V
N160-N250 380-500 V
N200-N315 380-480 V
N160-N315 525-690 V
N200-N400 525-690 V
Power & Voltage
P560 380-500 V
P630 380-500 V
P900 525-690 V
MG34S202 - Rev. 2013-08-19
Type
ABB OETL-NF600A
ABB OETL-NF600A
ABB OETL-NF600A
ABB OETL-NF600A
ABB OETL-NF800A
ABB OETL-NF800A
ABB OETL-NF800A
ABB OT800U21
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NPJF36000S12AAYP
ABB OT400U12-121
ABB OT400U12-121
ABB OT400U12-121
ABB OT400U12-121
ABB OETL-NF600A
ABB OETL-NF600A
ABB OT800U21
ABB OT800U21
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NPJF36000S12AAYP
Contactor
GE CK95CE311N
GE CK95BE311N
GE CK95CE311N
GE CK95BE311N
GE CK11CE311N
Contactor
Eaton XTCE650N22A
Eaton XTCE820N22A
Eaton XTCEC14P22B
Eaton XTCE820N22A
Eaton XTCEC14P22B
