Mechanical Installation
6
6
Illustration 6.2 Recommended Lifting Method, D-frame Size
Illustration 6.3 Recommended Lifting Method, E-frame Size
Illustration 6.4 Recommended Lifting Method, Frame Sizes F1,
F2, F9 and F10
98
®
VLT
AutomationDrive FC 300 Design Guide 90-1200 kW
Illustration 6.5 Recommended Lifting Method, Frame Sizes F3,
F4, F11, F12 and F13
Illustration 6.6 Recommended Lifting Method, Frame Size F8
NOTICE
The pedestal is packaged separately and included in the
shipment. Mount the frequency converter on the
pedestal in its final location. The pedestal allows proper
airflow and cooling to the frequency converter. See
6.2.13 Pedestal Installation of F-frames.
