Mechanical Installation
F
E
D
C
Illustration 6.66 IP00 Enclosure Power Connections, Position of Disconnect Switch
Frame size
Unit type
IP00/CHASSIS
250/315 kW (400 V) and
E2
355/450-500/630 KW (690 V)
315/355-400/450 kW (400 V)
Table 6.34 Disconnect Terminal Locations - Frame Size E2
®
VLT
AutomationDrive FC 300 Design Guide 90-1200 kW
0[0.0]
B
0[0.0]
A
381 (15.0)
383 (15.1)
MG34S202 - Rev. 2013-08-19
A
Dimension for disconnect terminal, mm (in)
B
C
D
245 (9.6)
334 (13.1)
423 (16.7)
244 (9.6)
334 (13.1)
424 (16.7)
6
0[0.0]
E
F
256 (10.1)
N/A
109 (4.3)
149 (5.8)
137
6
