Electrical Installation
Frame
size
P450 380-500 V & P630-P710
F3
P500-P630 380-500 V & P800
F3
P710 380-500 V & P900-P1M2
F4
F4
Table 7.58 F-frame Circuit Breakers
7.3 Disconnectors and Contactors
7.3.1 Mains Disconnects - Frame Sizes E and F
7
7
Frame size
380-500 V
D5h/D6h
D7h/D8h
E1/E2
E1/E2
F3
F3
F4
525-690 V
D5h/D6h
D7h/D8h
E1/E2
F3
F3
F4
Table 7.59 Mains Disconnects, 6-Pulse Frequency Converters
196
VLT
Power & Voltage
525-690 V
NPJF36120U31AABSCYP
525-690 V
NRJF36200U31AABSCYP
525-690 V
NRJF36200U31AABSCYP
P800 380-500 V
NRJF36250U31AABSCYP
Power
N55K-N132
N160-N315
P250
P315-P400
P450
P500-P630
P710-P800
N90K-N132
N160-N250
P355-P560
P630-P710
P800
P900-P1M2
®
AutomationDrive FC 300 Design Guide 90-1200 kW
Type
Trip level [A]
Merlin Gerin
Merlin Gerin
Merlin Gerin
Merlin Gerin
MG34S202 - Rev. 2013-08-19
Default breaker settings
Time [s]
1200
2000
2000
2500
Type
ABB OT400U03
ABB OT600U03
ABB OETL-NF600A
ABB OETL-NF800A
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NRKF36000S20AAYP
Merlin Gerin NRKF36000S20AAYP
ABB OT400U03
ABB OT600U03
ABB OETL-NF600A
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NRKF36000S20AAYP
Merlin Gerin NRKF36000S20AAYP
0.5
0.5
0.5
0.5
