Electrical Installation
Terminal Locations - Rectifier (F1, F2, F3 and F4)
Take the following position of the terminals into consideration when designing the cable access.
6
7 7
Illustration 7.28 Terminal Locations - Rectifier. Gland Plate is 42 mm below .0 Level.
1 Left Side
2 Front Side
3 Right Side
Table 7.20 Legend to Illustration 7.28
182
VLT
1
435.5 [17.15]
343.1 [13.51]
193.9 [7.64]
70.4 [2.77]
0.0 [0.00]
®
AutomationDrive FC 300 Design Guide 90-1200 kW
2
CH22 CH22 CH22 CH22 CH22 CH22
CTI25MB CTI25MB
FASTENER TORQUE: M8 9.6 Nm (7 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
R/L1 91 S/L2 92 T/L3 93
FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
DC 89 DC 89
4 Loadshare Terminal (-)
5 Earth ground bar
6 Loadshare Terminal (+)
MG34S202 - Rev. 2013-08-19
3
5
LOAD SHARE LOCATION
DIM F1/F2
A 380.5 [14.98] 29.4 [1.16]
B 432.5 [17.03] 81.4 [3.20]
4
F3/F4
