Danfoss VLT AutomationDrive FC 300 Design Manual page 141

Mechanical Installation
Illustration 6.68 Terminal Locations - Regeneration Terminals
for F1 and F3
Terminal Locations - Frame Size F2 and F4
1
FASTENER TORQUE: MIO 19 Nm (14 FT -LB) FASTENER TORQUE: MIO 19 Nm (14 FT -LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97 W/T3 98
Illustration 6.69 Terminal Locations - Inverter Cabinet. Gland Plate is 42 mm below .0 Level.
1 Front View
2 Left Side View
3 Right Side View
4 Brake Terminals
5 Earth/Ground bar
Table 6.36 Legend to Illustration 6.69
®
VLT AutomationDrive FC 300 Design Guide 90-1200 kW
DC '-'
1739.1
805.0
765.0
1694.1
DC '+'
1654.1
710.0
FASTENER TORQUE: MIO 19 Nm (14 FT -LB)
U/T1 96 V/T2 97 W/T3 98
6
MG34S202 - Rev. 2013-08-19
2
4
308.3 [12.14]
253.1 [9.96]
180.3 [7.10]
5
0.0 [0.00]
4
6 6
3
139
