Electrical Installation
Terminal Locations - Options Cabinet with Circuit Breaker/Molded Case Switch (F3 and F4)
Take the following position of the terminals into consideration when designing the cable access.
7 7
Illustration 7.30 Terminal Locations - Options Cabinet with Circuit Breaker/Molded Case Switch. Gland Plate is 42 mm below .0 Level.
1 Left Side
2 Front Side
Table 7.22 Legend to Illustration 7.30
Power size
450 kW (480 V), 630-710 kW (690 V)
500-800 kW (480 V), 800-1000 kW (690 V)
Table 7.23 Dimension for Terminal
184
®
VLT AutomationDrive FC 300 Design Guide 90-1200 kW
134.6 [5.30]
0.0 [0.00]
3 Right Side
4 Earth ground bar
2
34.9
46.3
MG34S202 - Rev. 2013-08-19
532.9 [20.98]
436.9 [17.20]
1
0.0 [0.00]
44.4 [1.75]
244.4 [9.62]
3 5
2 4
3 4
86.9 122.2
98.3 119.0
5
174.2
171.0
