Mechanical Installation
FASTENER TORQUE: M8 9.6 Nm [7 FT-LB]
FASTENER TORQUE: M10 19 Nm [14 FT-LB]
R/L1 91
S/L2 92
F
19 Nm [14FT-LB]
/T1 96
E
Illustration 6.63 IP21 (NEMA type 1) and IP54 (NEMA type 12) Enclosure Power Connection Position of Disconnect Switch
Frame size
Unit type
IP54/IP21 UL and NEMA1/NEMA12
250/315 kW (400 V) and
E1
355/450-500/630 KW (690 V)
315/355-400/450 kW (400 V)
Table 6.33 Legend to Illustration 6.63
®
VLT
AutomationDrive FC 300 Design Guide 90-1200 kW
T/L3 93
V/T2 97
V/T3 9
0[0.0]
A
381 (15.0)
371 (14.6)
MG34S202 - Rev. 2013-08-19
144[5.7]
26[1.0]
Dimension for disconnect terminal, mm (in)
B
C
D
253 (9.9)
342 (13.5)
431 (17.0)
251 (9.9)
341 (13.4)
431 (17.0)
26[1.0]
391[15.4]
E
F
562 (22.1)
N/A
416 (16.4)
455 (17.9)
135
